STC120T4 Sany crane - load chart, specs & dimensions (2025 - 2026)

max. carrying capacity: 12t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 22m – max. standard boom: 28.1m – Min. stand…

max. carrying capacity: 12t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 22m – max. standard boom: 28.1m – Min. standard boom: 8.7m

See load chart, specs, capacity, size and other technical data for Sany STC120T4 crane manufactured between 2025 - 2026. See information, like: max. carrying capacity: 12t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 22m – max. standard boom: 28.1m – Min. standard boom: 8.7m and more.

All-terrain Cranes Sany STC120T4
All-terrain Cranes Sany STC120T4
All-terrain Cranes Sany STC120T4
All-terrain Cranes Sany STC120T4

Visit Sany live at

Technical specs - STC120T4 Sany

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

max. carrying capacity
12 t
at reach
3 m
Carrying capacity
0.6 t
at max. reach
22 m
max. standard boom
28.1 m
Min. standard boom
8.7 m
max. hook height
28.1 m
Load Torque
397 kNm
Travel speed
90 km/h
Number of axles
2
Wheels/Drive/Steering
4x2
axle load
14 t
Standard tyres
8.25R20
Outriggers spacing length
4.65 m
Outriggers spacing width
5.4 m
Model series
STC
Engine manuf.
Yuchai
Engine type
YCS4200-30
Engine power
147 kW
Revolutions at max torque
2300 rpm
Max. torque
720/1600 Nm
No. of cylinders
4
Emission level
Euro III

More technical details, like: max. luffing jib, undercarriage engine, superstructure engine, tipping load, dimension lxwxh, displacement, cylinder bore x stroke, weight are available in the full technical specs.

Including hook block

Special equipment

2nd winch
No
max. luffing jib
No
max. fold hydr.
No
Erection tip
No
Foucault current brake
No
Add. ballast
No
