Liebherr LTM 1150-5.3 crane - load chart, specs (2021 - 2025)

Name: Liebherr LTM 1150-5.3 All-terrain Cranes
Brand: Liebherr

max. carrying capacity: 150t – at reach: 3m – Carrying capacity: 1.1t – at max. reach: 72m – max. standard boom: 60m – Min. standa…

max. carrying capacity: 150t – at reach: 3m – Carrying capacity: 1.1t – at max. reach: 72m – max. standard boom: 60m – Min. standard boom: 12.3m

See load chart, specs, capacity, size and other technical data for Liebherr LTM 1150-5.3 crane manufactured between 2021 - 2025. See information, like: max. carrying capacity: 150t – at reach: 3m – Carrying capacity: 1.1t – at max. reach: 72m – max. standard boom: 60m – Min. standard boom: 12.3m and more.

All-terrain Cranes Liebherr LTM 1150-5.3

LTM 1150-5.3

Years of manufacture: 2021—2025

Data sheet
Buy & Rent
Spare parts
Transport
Events & News

Technical specs - LTM 1150-5.3 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

max. carrying capacity: 150 t

at reach: 3 m

Carrying capacity: 1.1 t

at max. reach: 72 m

max. standard boom: 60 m

Min. standard boom: 12.3 m

Max. luffing jib: 26 m

max. hook height: 92 m

Load Torque: 4690 kNm

Undercarriage engine: 400 kW

Travel speed: 85 km/h

Number of axles: 5

Wheels/Drive/Steering: 10/6/10

Standard tyres: 445/95 R25

Outriggers spacing length: 8.074 m

Outriggers spacing width: 7.874 m

Model series: LTM

Engine manuf.: Liebherr

Engine type: N/A

Engine power: 400 kW

Max. torque: 2516 Nm

No. of cylinders: 6

Emission level: EPA

More technical details, like: superstructure engine, axle load, tipping load, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, weight are available in the full technical specs.

Including hook block

Special equipment

2nd winch: Yes
max. luffing jib: Yes
max. fold hydr.: Yes
Erection tip: Yes
Foucault current brake: No
Add. ballast: Yes
