Technical specs - V7-HW Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.45 t

Standard tyres: 340/80-18

Bucket width: 1.85 m

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Bucket capacity max.: 1.2 m³

Steering mode: KL

Transport length: 5.238 m

Transport width: 1.85 m

Transport height: 2.499 m

Travel speed: 20 km/h

Max. discharge height: 2.497 m

Turning radius outside: 4.203 m

Lifting force: 41 kN

Model series: V

Engine manuf.: Yanmar

Engine type: 4TNV86CT

Engine power: 35.5 kW

Displacement: 2.091 l

Max. torque: 177/1560 Nm

No. of cylinders: 4

Emission level: EU V / EPA Tier 4

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Yanmar V7-HW FAQ

When was the Yanmar V7-HW manufactured?

The Yanmar V7-HW was first produced in 2024.

How much does the Yanmar V7-HW wheel loader weigh?

The Yanmar V7-HW wheel loader weighs 4.45 tons.

What are the transport dimensions of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW has a transport length of 5.238 meters, a transport width of 1.85 meters, and a transport height of 2.499 meters.

What is the travel speed of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW has a travel speed of 20 km/h.

What are the undercarriage specifications of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW wheel loader is equipped with standard tyres sized 340/80-18.

What are the maneuverability specifications of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW wheel loader has an articulated-frame steering mode and an outside turning radius of 4.203 meters.

What is the lifting force rating of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW wheel loader has a lifting force of 41 kN.

What is the maximum discharge height of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW wheel loader has a maximum discharge height of 2.497 meters.

What are the bucket specifications of the Yanmar V7-HW wheel loader?

The Yanmar V7-HW wheel loader has a bucket capacity ranging from 0.8 to 1.2 cubic meters, with a bucket width of 1.85 meters.
