V7 Yanmar V7 Specifications & Technical Data (2024—2026)

Weight: 4.25t – Standard tyres: 340/80-18 – Bucket width: 1.85m – Bucket capacity: 0.7m³ – Bucket capacity min.: 0.7m³ – Bucket capacity max.: 1.2m³

Years of manufacture: 2024—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - V7 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.25 t

Standard tyres: 340/80-18

Bucket width: 1.85 m

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1.2 m³

Steering mode: KL

Transport length: 5.238 m

Transport width: 1.793 m

Transport height: 2.499 m

Travel speed: 20 km/h

Max. discharge height: 2.497 m

Turning radius outside: 4.203 m

Lifting force: 41 kN

Model series: V

Engine manuf.: Yanmar

Engine type: 4TNV86CT

Engine power: 35.5 kW

Displacement: 2.091 l

Max. torque: 177/1560 Nm

No. of cylinders: 4

Emission level: EU V / EPA Tier 4

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Yanmar V7 FAQ

When was the Yanmar V7 manufactured?

The Yanmar V7 was first produced in 2024.

How much does the Yanmar V7 wheel loader weigh?

The Yanmar V7 wheel loader weighs 4.25 tons.

What are the transport dimensions of the Yanmar V7 wheel loader?

The Yanmar V7 wheel loader has a transport length of 5.238 meters, a transport width of 1.793 meters, and a transport height of 2.499 meters.

What is the travel speed of the Yanmar V7 wheel loader?

The Yanmar V7 wheel loader has a travel speed of 20 km/h.

What is the size of the standard tyres on the Yanmar V7 wheel loader?

The Yanmar V7 wheel loader is equipped with standard tyres sized 340/80-18.

What are the maneuverability specifications of the Yanmar V7 wheel loader?

The Yanmar V7 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.203 meters.

What are the power ratings of the Yanmar V7 wheel loader?

The source data does not provide power ratings for the Yanmar V7 wheel loader.

What is the maximum discharge height of the Yanmar V7?

The Yanmar V7 has a maximum discharge height of 2.497 meters.

What are the specifications of the bucket on the Yanmar V7 wheel loader?

The Yanmar V7 wheel loader has a bucket with a capacity ranging from 0.7 to 1.2 cubic meters and a width of 1.85 meters.

How much is a Yanmar V7 Wheel loader (2024u20132025) worth?

The residual value of the Yanmar V7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
