V 7 Yanmar V 7 Specifications & Technical Data (2015—2020)

The Yanmar V 7 is a wheel loader manufactured from 2015 to 2020. It has a weight of 4.1 tons and a transport length of 4.8 meters.…

The Yanmar V 7 is a wheel loader manufactured from 2015 to 2020. It has a weight of 4.1 tons and a transport length of 4.8 meters. The bucket capacity is 0.7 cubic meters, with a bucket width of 1.7 meters. The maximum discharge height is 2.45 meters, and it has a travel speed of 20 km/h. The transport width and height are both 1.7 and 2.46 meters, respectively. It has a lifting force of 46.1 kN and a turning radius outside of 4.21 meters. Special equipment includes air conditioning and a quick hitch hydraulic mechanism.

Wheel Loaders Yanmar V 7

Technical specs - V 7 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.1 t
Standard tyres
12.0/75 R18
Bucket width
1.7 m
Bucket capacity
0.7 m³
Bucket capacity min.
0.7 m³
Steering mode
KL
Transport length
4.8 m
Transport width
1.7 m
Transport height
2.46 m
Travel speed
20 km/h
Max. discharge height
2.45 m
Turning radius outside
4.21 m
Lifting force
46.1 kN
Model series
V
Engine manuf.
Yanmar
Engine type
4TNV88
Engine power
35 kW
Emission level
Tier 3 a

More technical details, like: bucket capacity max., dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar V 7 FAQ

When was the Yanmar V 7 manufactured?

The Yanmar V 7 was manufactured from 2015 to 2020.

How much does the Yanmar V 7 wheel loader weigh?

The Yanmar V 7 wheel loader weighs 4.1 tons.

What are the transport dimensions of the Yanmar V 7 wheel loader?

The Yanmar V 7 has a transport length of 4.8 meters, a transport width of 1.7 meters, and a transport height of 2.46 meters.

What is the travel speed of the Yanmar V 7 wheel loader?

The Yanmar V 7 has a travel speed of 20 km/h.

What is the standard tyre size of the Yanmar V 7 wheel loader's undercarriage?

The Yanmar V 7 wheel loader has standard tyres sized 12.0/75 R18.

What are the maneuverability specifications of the Yanmar V 7 wheel loader?

The Yanmar V 7 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.21 meters.

What is the lifting force of the Yanmar V 7 wheel loader?

The Yanmar V 7 wheel loader has a lifting force of 46.1 kN.

What is the maximum discharge height of the Yanmar V 7?

The Yanmar V 7 has a maximum discharge height of 2.45 meters.

What are the bucket specifications of the Yanmar V 7 wheel loader?

The Yanmar V 7 wheel loader has a bucket capacity of 0.7 cubic meters, a minimum bucket capacity of 0.7 cubic meters, and a bucket width of 1.7 meters.

How much is a Yanmar V 7 Wheel loader (2015u20132020) worth?

The residual value of the Yanmar V 7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
