AR 60 weycor AR 60 Specifications & Technical Data (2016—2019)

The Weycor AR 60 is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 4.3 tons and a transport length of…

The Weycor AR 60 is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 4.3 tons and a transport length of 5.25 meters. The bucket capacity is 0.8 cubic meters with a width of 1.9 meters. The maximum discharge height is 2.48 meters. It has a travel speed of 20 km/h and a transport width of 1.79 meters. The transport height is also 2.48 meters. The lifting force is 47 kN and the turning radius outside is 3.69 meters. It is equipped with a quick hitch hydr. and quick hitch mech. for special operations.

Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60
Wheel Loaders weycor AR 60

Visit weycor live at

Technical specs - AR 60 weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.3 t
Standard tyres
12.5-18 MPT
Bucket width
1.9 m
Bucket capacity
0.8 m³
Bucket capacity min.
0.8 m³
Steering mode
KL
Transport length
5.25 m
Transport width
1.79 m
Transport height
2.48 m
Travel speed
20 km/h
Max. discharge height
2.48 m
Turning radius outside
3.69 m
Lifting force
47 kN
Model series
AR
Engine manuf.
Yanmar
Engine type
4TNV88BD
Engine power
37 kW
Displacement
2.19 l
Revolutions at max torque
1800 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

weycor AR 60 FAQ

When was the weycor AR 60 manufactured?

The weycor AR 60 was manufactured from 2016 to 2019.

How much does the weycor AR 60 wheel loader weigh?

The weycor AR 60 wheel loader weighs 4.3 tons.

What are the transport dimensions of the weycor AR 60 wheel loader?

The transport dimensions of the weycor AR 60 are 5.25 meters in length, 1.79 meters in width, and 2.48 meters in height.

What is the travel speed of the weycor AR 60 wheel loader?

The weycor AR 60 wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the weycor AR 60 wheel loader?

The weycor AR 60 wheel loader is equipped with standard tyres sized 12.5-18 MPT.

What are the maneuverability specifications of the weycor AR 60 wheel loader?

The weycor AR 60 wheel loader has an articulated-frame steering mode and an outside turning radius of 3.69 meters.

What is the lifting force of the weycor AR 60 wheel loader?

The weycor AR 60 wheel loader has a lifting force of 47 kN.

What is the material handling capacity of the weycor AR 60 in terms of discharge height?

The weycor AR 60 has a maximum discharge height of 2.48 meters for material handling.

What are the specifications of the bucket on the weycor AR 60 wheel loader?

The weycor AR 60 wheel loader has a bucket capacity of 0.8 cubic meters, a minimum bucket capacity of 0.8 cubic meters, and a bucket width of 1.9 meters.
