AR 40 weycor AR 40 Specifications & Technical Data (2016—2019)

The Weycor AR 40 is a wheel loader manufactured from 2016 to 2019. It has a weight of 3.5 tons and a transport length of 4.36 mete…

The Weycor AR 40 is a wheel loader manufactured from 2016 to 2019. It has a weight of 3.5 tons and a transport length of 4.36 meters. The bucket capacity is 0.5 cubic meters, with a bucket width of 1.6 meters. The maximum discharge height is 2.34 meters, and it has a travel speed of 20 km/h. The transport width is 1.5 meters, and the transport height is 2.38 meters. It has a lifting force of 25 kN and a turning radius outside of 3.15 meters. Special equipment includes a quick hitch hydraulic mechanism and a quick hitch mechanism.

Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40
Wheel Loaders weycor AR 40

Visit weycor live at

Technical specs - AR 40 weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.5 t
Standard tyres
15.0/55-17
Bucket width
1.6 m
Bucket capacity
0.5 m³
Bucket capacity min.
0.5 m³
Steering mode
KL
Transport length
4.36 m
Transport width
1.5 m
Transport height
2.38 m
Travel speed
20 km/h
Max. discharge height
2.34 m
Turning radius outside
3.15 m
Lifting force
25 kN
Model series
AR
Engine manuf.
Perkins
Engine type
403D-15T
Engine power
30 kW
Displacement
1.5 l
Revolutions at max torque
2800 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

weycor AR 40 FAQ

When was the weycor AR 40 manufactured?

The weycor AR 40 was manufactured from 2016 to 2019.

How much does the Weycor AR 40 wheel loader weigh?

The Weycor AR 40 wheel loader weighs 3.5 tons.

What are the transport dimensions of the weycor AR 40 wheel loader?

The transport dimensions of the weycor AR 40 are 4.36 meters in length, 1.5 meters in width, and 2.38 meters in height.

What is the travel speed of the weycor AR 40 wheel loader?

The weycor AR 40 wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Weycor AR 40 wheel loader?

The Weycor AR 40 wheel loader has standard tyres sized 15.0/55-17.

What are the maneuverability specifications of the weycor AR 40 wheel loader?

The weycor AR 40 wheel loader has an articulated-frame steering system and an outside turning radius of 3.15 meters.

What is the lifting force of the weycor AR 40 wheel loader?

The weycor AR 40 wheel loader has a lifting force of 25 kN.

What is the material handling capacity of the weycor AR 40 in terms of maximum discharge height?

The weycor AR 40 has a maximum discharge height of 2.34 meters.

What are the specifications of the bucket on the weycor AR 40 wheel loader?

The bucket of the weycor AR 40 has a capacity of 0.5 cubic meters, a minimum capacity of 0.5 cubic meters, and a width of 1.6 meters.

How much is a weycor AR 40 Wheel loader (2016u20132019) worth?

The residual value of the weycor AR 40 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
