AR 380 weycor AR 380 Specifications & Technical Data (2022—2026)

The Weycor AR 380 is a wheel loader manufactured since 2022. It has a weight of 3.5 tons and a transport length of 4.58 meters. Th…

The Weycor AR 380 is a wheel loader manufactured since 2022. It has a weight of 3.5 tons and a transport length of 4.58 meters. The bucket capacity is 0.5 cubic meters with a width of 1.55 meters. The maximum discharge height is 2.36 meters. It has a travel speed of 20 km/h and a transport width of 1.5 meters. The transport height is 2.46 meters and the turning radius outside is 3.09 meters. The maximum bucket capacity is 0.6 cubic meters and the minimum bucket capacity is 0.36 cubic meters.

Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380
Wheel Loaders weycor AR 380

Visit weycor live at

Technical specs - AR 380 weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.5 t
Standard tyres
15.0 / 55 - 17
Bucket width
1.55 m
Bucket capacity
0.5 m³
Bucket capacity min.
0.36 m³
Bucket capacity max.
0.6 m³
Steering mode
KL
Transport length
4.58 m
Transport width
1.5 m
Transport height
2.46 m
Travel speed
20 km/h
Max. discharge height
2.36 m
Turning radius outside
3.09 m
Model series
AR
Engine manuf.
Kubota
Engine type
D 1803-CR-T
Engine power
37 kW
Displacement
1.826 l
Revolutions at max torque
2700 rpm
Max. torque
150/1600 Nm
No. of cylinders
3
Emission level
V

More technical details, like: lifting force, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

weycor AR 380 FAQ

When was the weycor AR 380 manufactured?

The weycor AR 380 was first produced in 2022.

How much does the weycor AR 380 wheel loader weigh?

The weycor AR 380 wheel loader weighs 3.5 tons.

What are the transport dimensions of the weycor AR 380 wheel loader?

The weycor AR 380 has a transport length of 4.58 meters, a transport width of 1.5 meters, and a transport height of 2.46 meters.

What is the travel speed of the weycor AR 380 wheel loader?

The weycor AR 380 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Weycor AR 380 wheel loader?

The Weycor AR 380 wheel loader is equipped with standard tyres sized 15.0 / 55 - 17.

What are the maneuverability specifications of the weycor AR 380 wheel loader?

The weycor AR 380 wheel loader has an articulated-frame steering mode and an outside turning radius of 3.09 meters.

What is the maximum discharge height of the weycor AR 380?

The weycor AR 380 has a maximum discharge height of 2.36 meters.

What are the bucket specifications of the weycor AR 380 wheel loader?

The weycor AR 380 wheel loader has a bucket capacity of 0.5 mu00b3, with a maximum capacity of 0.6 mu00b3 and a minimum capacity of 0.36 mu00b3, and a bucket width of 1.55 meters.

How much is a weycor AR 380 Wheel loader (2022u20132025) worth?

The residual value of the weycor AR 380 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
