3080LP Weidemann 3080LP Specifications & Technical Data (2016—2019)

The Weidemann 3080LP is a wheel loader manufactured by Weidemann from 2016 to 2019. It has a weight of 4.6 tons and a transport le…

The Weidemann 3080LP is a wheel loader manufactured by Weidemann from 2016 to 2019. It has a weight of 4.6 tons and a transport length of 5 meters. The maximum discharge height is 2.47 meters and it has a travel speed of 20 km/h. The transport width is 1 meter and the transport height is 2 meters. The turning radius outside is 4 meters. This construction machine is equipped with a diesel particulate filter and a quick hitch hydr.

3080LP

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 3080LP Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.6 t

Standard tyres: 11.5/80-15.3 AS ET 80

Steering mode: KL

Transport length: 5.542 m

Transport width: 1.530 m

Transport height: 2.409 m

Travel speed: 20 km/h

Max. discharge height: 2.47 m

Turning radius outside: 4.105 m

Engine manuf.: Perkins

Engine type: 404F 22T

Engine power: 44.7 kW

Displacement: 2.216 l

Revolutions at max torque: 2800 rpm

No. of cylinders: 4

Emission level: III B

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

3080LP Weidemann Specification for Europe (DE)

Weidemann 3080LP FAQ

When was the Weidemann 3080LP manufactured?

The Weidemann 3080LP was manufactured from 2016 to 2019.

How much does the Weidemann 3080LP weigh?

The Weidemann 3080LP weighs 4.6 tons.

What are the transport dimensions of the Weidemann 3080LP wheel loader?

The Weidemann 3080LP has a transport length of 5.54 meters, a transport width of 1.53 meters, and a transport height of 2.41 meters.

What is the travel speed of the Weidemann 3080LP wheel loader?

The Weidemann 3080LP has a travel speed of 20 km/h.

What are the undercarriage specifications of the Weidemann 3080LP wheel loader?

The Weidemann 3080LP wheel loader is equipped with standard tyres sized 11.5/80-15.3 AS ET 80.

What are the maneuverability specifications of the Weidemann 3080LP wheel loader?

The Weidemann 3080LP has an articulated-frame steering mode and an outside turning radius of 4.105 meters.

What is the material handling capacity of the Weidemann 3080LP in terms of discharge height?

The Weidemann 3080LP has a maximum discharge height of 2.47 meters.

How much is a Weidemann 3080LP Wheel loader (2016u20132019) worth?

The residual value of the Weidemann 3080LP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
