3080 LP Weidemann 3080 LP Specifications & Technical Data (2019—2024)

The Weidemann 3080 LP is a wheel loader manufactured since 2019. It has a weight of 4.6 tons and a transport length of 5.542 meter…

The Weidemann 3080 LP is a wheel loader manufactured since 2019. It has a weight of 4.6 tons and a transport length of 5.542 meters. The maximum discharge height is 2.47 meters and it can travel at a speed of 20 km/h. The transport width is 1.53 meters and the transport height is 2.409 meters. Special equipment includes a diesel particulate filter and a quick hitch hydraulic mechanism.

3080 LP

Years of manufacture: 2019—2024

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 3080 LP Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.6 t

Standard tyres: 11.5/80-15.3 AS ET 80

Steering mode: KL

Transport length: 5.54 m

Transport width: 1.53 m

Transport height: 2.41 m

Travel speed: 20 km/h

Max. discharge height: 2.47 m

Turning radius outside: 4.105 m

Engine manuf.: Deutz

Engine type: TD2.9 L4 S5

Engine power: 45 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Weidemann 3080 LP FAQ

When was the Weidemann 3080 LP manufactured?

The Weidemann 3080 LP was manufactured from 2019 to 2024.

How much does the Weidemann 3080 LP weigh?

The Weidemann 3080 LP weighs 4.6 tons.

What are the transport dimensions of the Weidemann 3080 LP wheel loader?

The Weidemann 3080 LP has a transport length of 5.54 meters, a transport width of 1.53 meters, and a transport height of 2.41 meters.

What is the travel speed of the Weidemann 3080 LP wheel loader?

The Weidemann 3080 LP has a travel speed of 20 km/h.

What are the standard tyre specifications of the Weidemann 3080 LP's undercarriage?

The Weidemann 3080 LP has standard tyres sized 11.5/80-15.3 AS ET 80.

What are the maneuverability specifications of the Weidemann 3080 LP wheel loader?

The Weidemann 3080 LP features articulated-frame steering and has an outside turning radius of 4.105 meters.

What is the maximum discharge height of the Weidemann 3080 LP?

The Weidemann 3080 LP has a maximum discharge height of 2.47 meters.

How much is a Weidemann 3080 LP Wheel loader (2019u20132024) worth?

The residual value of the Weidemann 3080 LP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
