WL60 Wacker Neuson WL60 Specifications & Technical Data (2019—2023)

The Wacker Neuson WL60 is a wheel loader that has been manufactured since 2019. It has a weight of 5.93 tons and a transport lengt…

The Wacker Neuson WL60 is a wheel loader that has been manufactured since 2019. It has a weight of 5.93 tons and a transport length of 4.78 meters. The bucket capacity is 1 cubic meter, with a bucket width of 2 meters. The maximum discharge height is 2.841 meters. It has a travel speed of 28 km/h and a transport width of 1.829 meters. The transport height is 2.693 meters and the turning radius outside is 3.686 meters. The machine is equipped with a quick hitch hydr.

Visit Wacker Neuson live at

WL60

Years of manufacture: 2019—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - WL60 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.93 t

Standard tyres: 405/70 R 18 EM ET 0

Bucket width: 2 m

Bucket capacity: 1 m³

Steering mode: KL

Transport length: 4.78 m

Transport width: 1.829 m

Transport height: 2.693 m

Travel speed: 28 km/h

Max. discharge height: 2.841 m

Turning radius outside: 3.686 m

Model series: WL

Engine manuf.: Perkins

Engine type: 854E-E34TAWF

Engine power: 75 kW

Displacement: 3.4 l

Revolutions at max torque: 2500 rpm

No. of cylinders: 4

Emission level: IV

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Wacker Neuson WL60 FAQ

When was the Wacker Neuson WL60 manufactured?

The Wacker Neuson WL60 was manufactured from 2019 to 2023.

How much does the Wacker Neuson WL60 weigh?

The Wacker Neuson WL60 weighs 5.93 tons.

What are the transport dimensions of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a transport length of 4.78 meters, a transport width of 1.83 meters, and a transport height of 2.69 meters.

What is the travel speed of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a travel speed of 28 km/h.

What are the undercarriage specifications of the Wacker Neuson WL60?

The Wacker Neuson WL60 is equipped with standard tyres sized 405/70 R 18 EM ET 0.

What are the maneuverability specifications of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has an articulated-frame steering system and an outside turning radius of 3.686 meters.

What is the maximum discharge height of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a maximum discharge height of 2.84 meters.

What are the specifications of the bucket on the Wacker Neuson WL60 wheel loader?

The bucket of the Wacker Neuson WL60 has a capacity of 1 cubic meter and a width of 2 meters.

How much is a Wacker Neuson WL60 Wheel loader (2019u20132023) worth?

The residual value of the Wacker Neuson WL60 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
