WL 36 Wacker Neuson WL 36 Specifications & Technical Data (2007—2014)

The Wacker Neuson WL 36 is a wheel loader that was manufactured from 2007 to 2014. It has a weight of 3.63 tons and a transport le…

The Wacker Neuson WL 36 is a wheel loader that was manufactured from 2007 to 2014. It has a weight of 3.63 tons and a transport length of 4.13 meters. The maximum discharge height is 2.428 meters and it has a travel speed of 20 km/h. The transport width is 1.56 meters and the transport height is 2.31 meters. The lifting force of this wheel loader is 37.06 kN and it has a turning radius outside of 1.674 meters. The bucket capacity ranges from a minimum of 0.65 cubic meters to a maximum of 0.65 cubic meters. It is equipped with a quick hitch mechanism.

Visit Wacker Neuson live at

WL 36

Years of manufacture: 2007—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - WL 36 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.63 t

Standard tyres: 15.5/55-18 EM

Bucket capacity min.: 0.65 m³

Bucket capacity max.: 0.65 m³

Steering mode: KL

Transport length: 4.13 m

Transport width: 1.56 m

Transport height: 2.31 m

Travel speed: 20 km/h

Max. discharge height: 2.428 m

Turning radius outside: 1.674 m

Lifting force: 37.06 kN

Model series: WL

Engine manuf.: Perkins

Engine type: 404C-22

Engine power: 35.7 kW

Displacement: 2.216 l

Revolutions at max torque: 2600 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Wacker Neuson WL 36 FAQ

When was the Wacker Neuson WL 36 manufactured?

The Wacker Neuson WL 36 was manufactured from 2007 to 2014.

How much does the Wacker Neuson WL 36 weigh?

The Wacker Neuson WL 36 weighs 3.63 tons.

What are the transport dimensions of the Wacker Neuson WL 36 wheel loader?

The Wacker Neuson WL 36 has a transport length of 4.13 meters, a transport width of 1.56 meters, and a transport height of 2.31 meters.

What is the travel speed of the Wacker Neuson WL 36?

The Wacker Neuson WL 36 has a travel speed of 20 km/h.

What are the standard tyres of the Wacker Neuson WL 36?

The Wacker Neuson WL 36 has standard tyres sized 15.5/55-18 EM.

What are the maneuverability specifications of the Wacker Neuson WL 36 wheel loader?

The Wacker Neuson WL 36 has an articulated-frame steering system and an outside turning radius of 1.674 meters.

What is the lifting force of the Wacker Neuson WL 36?

The Wacker Neuson WL 36 has a lifting force of 37.06 kN.

What is the maximum discharge height of the Wacker Neuson WL 36?

The Wacker Neuson WL 36 has a maximum discharge height of 2.43 meters.

What is the bucket capacity of the Wacker Neuson WL 36 wheel loader?

The Wacker Neuson WL 36 wheel loader has a bucket capacity of 0.65 cubic meters.
