LH 410 TORO LH 410 Specifications & Technical Data (2008—2011)

The TORO LH 410 is a wheel loader manufactured by TORO from 2008 to 2011. It has a weight of 26.2 tons and a transport length of 1…

The TORO LH 410 is a wheel loader manufactured by TORO from 2008 to 2011. It has a weight of 26.2 tons and a transport length of 10.2 meters. The bucket capacity is 4.6 cubic meters with a width of 2.5 meters. The maximum discharge height is 3.5 meters. It has a travel speed of 27 km/h and a transport width of 2.55 meters. The transport height is 2.4 meters. The lifting force is 184 kN and the turning radius outside is 6.5 meters. The minimum bucket capacity is also 4.6 cubic meters.

LH 410

Years of manufacture: 2008—2011

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - LH 410 TORO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 26.2 t

Standard tyres: 18.00x25L5S

Bucket width: 2.5 m

Bucket capacity: 4.6 m³

Bucket capacity min.: 4.6 m³

Steering mode: KL

Transport length: 10.2 m

Transport width: 2.55 m

Transport height: 2.4 m

Travel speed: 27 km/h

Max. discharge height: 3.5 m

Turning radius outside: 6.5 m

Lifting force: 184 kN

Model series: LH

Engine manuf.: Mercedes-Benz

Engine type: OM926 LA

Engine power: 220 kW

Displacement: 7.2 l

Revolutions at max torque: 1400 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

TORO LH 410 FAQ

When was the TORO LH 410 manufactured?

The TORO LH 410 was manufactured from 2008 to 2011.

How much does the TORO LH 410 wheel loader weigh?

The TORO LH 410 wheel loader weighs 26.2 tons.

What are the transport dimensions of the TORO LH 410 wheel loader?

The TORO LH 410 has a transport length of 10.2 meters, a transport width of 2.55 meters, and a transport height of 2.4 meters.

What is the travel speed of the TORO LH 410 wheel loader?

The TORO LH 410 has a travel speed of 27 km/h.

What are the undercarriage specifications of the TORO LH 410 wheel loader?

The TORO LH 410 wheel loader is equipped with standard tyres sized 18.00x25L5S.

What are the maneuverability specifications of the TORO LH 410 wheel loader?

The TORO LH 410 has an articulated-frame steering system and an outside turning radius of 6.5 meters.

What is the lifting force of the TORO LH 410 wheel loader?

The TORO LH 410 wheel loader has a lifting force of 184 kN.

What is the maximum discharge height of the TORO LH 410?

The TORO LH 410 has a maximum discharge height of 3.5 meters.

What are the bucket specifications of the TORO LH 410 wheel loader?

The TORO LH 410 has a bucket capacity of 4.6 cubic meters, a minimum bucket capacity of 4.6 cubic meters, and a bucket width of 2.5 meters.
