TL 310 Terex TL 310 Specifications & Technical Data (2010—2016)

Model rating: 9,00 / 10

The Terex TL 310 is a wheel loader manufactured by Terex from 2010 to 2016. It has a weight of 17.6 tons and a transport length of…

The Terex TL 310 is a wheel loader manufactured by Terex from 2010 to 2016. It has a weight of 17.6 tons and a transport length of 7.6 meters. The bucket capacity is 3 cubic meters with a width of 2.95 meters. The maximum discharge height is 3.07 meters. It has a travel speed of 40 km/h and a transport width of 2.68 meters. The transport height is 3.4 meters. The lifting force is 232 kN and the turning radius outside is 6.48 meters. The bucket capacity minimum is 3 cubic meters. It is equipped with a quick hitch mechanism.

TL 310

Years of manufacture: 2010—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TL 310 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.6 t

Standard tyres: 23.5 R25

Bucket width: 2.95 m

Bucket capacity: 3 m³

Bucket capacity min.: 3 m³

Steering mode: KL

Transport length: 7.6 m

Transport width: 2.68 m

Transport height: 3.4 m

Travel speed: 40 km/h

Max. discharge height: 3.07 m

Turning radius outside: 6.48 m

Lifting force: 232 kN

Model series: TL

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 144 kW

Displacement: 6.7 l

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Terex TL 310 FAQ

When was the Terex TL 310 manufactured?

The Terex TL 310 was manufactured from 2010 to 2016.

How much does the Terex TL 310 weigh?

The Terex TL 310 weighs 17.6 tons.

What are the transport dimensions of the Terex TL 310 wheel loader?

The Terex TL 310 has a transport length of 7.6 meters, a transport width of 2.68 meters, and a transport height of 3.4 meters.

What is the travel speed of the Terex TL 310 wheel loader?

The Terex TL 310 has a travel speed of 40 km/h.

What are the standard tyre specifications of the Terex TL 310 wheel loader?

The Terex TL 310 wheel loader has standard tyres sized 23.5 R25.

What are the maneuverability specifications of the Terex TL 310 wheel loader?

The Terex TL 310 wheel loader has an outside turning radius of 6.48 meters and uses articulated-frame steering.

What is the lifting force rating of the Terex TL 310 wheel loader?

The Terex TL 310 wheel loader has a lifting force of 232 kN.

What is the maximum discharge height of the Terex TL 310 wheel loader?

The Terex TL 310 wheel loader has a maximum discharge height of 3.07 meters.

What are the bucket specifications of the Terex TL 310 wheel loader?

The Terex TL 310 wheel loader has a bucket capacity of 3 cubic meters, a minimum bucket capacity of 3 cubic meters, and a bucket width of 2.95 meters.

How much is a Terex TL 310 Wheel loader (2010u20132016) worth?

The residual value of the Terex TL 310 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Terex TL 310 overview

Operator's cab

Features

Excellent all-round visibilitySteel cab with perfectly designed operator's standEasy service accessibility for minimized downtimeErgonomically designed controls for fatigue-free operationSelf-locking differentials provide optimum tractionLoader frame with TSP kinematicsFuel efficient Cummins turbocharged diesel engineFully automatic VarioPower transmission for smooth acceleration up to 40 kph
