L 9 Sveloader L 9 Specifications & Technical Data (2007—2011)

The Sveloader L 9 is a wheel loader manufactured by Sveloader from 2007 to 2011. It has a weight of 9.8 tons and a transport lengt…

The Sveloader L 9 is a wheel loader manufactured by Sveloader from 2007 to 2011. It has a weight of 9.8 tons and a transport length of 6.66 meters. The bucket capacity is 1.6 cubic meters with a width of 2.6 meters. The maximum discharge height is 2.7 meters. It has a travel speed of 40 km/h and a transport width of 2.55 meters. The transport height is 3.24 meters. The lifting force is 550 kN and the turning radius outside is 4.7 meters. It is equipped with special features such as air conditioning and a quick hitch mechanism.

L 9

Years of manufacture: 2007—2011

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 9 Sveloader

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.8 t

Standard tyres: 17.5x25

Bucket width: 2.6 m

Bucket capacity: 1.6 m³

Bucket capacity min.: 1.6 m³

Steering mode: KL

Transport length: 6.66 m

Transport width: 2.55 m

Transport height: 3.24 m

Travel speed: 40 km/h

Max. discharge height: 2.7 m

Turning radius outside: 4.7 m

Lifting force: 550 kN

Engine manuf.: Mercedes-Benz

Engine type: OM904 LAT

Engine power: 130 kW

More technical details, like: bucket capacity max., model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Sveloader L 9 FAQ

When was the Sveloader L 9 manufactured?

The Sveloader L 9 was manufactured from 2007 to 2011.

How much does the Sveloader L 9 weigh?

The Sveloader L 9 weighs 9.8 tons.

What are the transport dimensions of the Sveloader L 9 wheel loader?

The Sveloader L 9 has a transport length of 6.66 meters, a transport width of 2.55 meters, and a transport height of 3.24 meters.

What is the travel speed of the Sveloader L 9 wheel loader?

The Sveloader L 9 has a travel speed of 40 km/h.

What are the undercarriage specifications of the Sveloader L 9?

The Sveloader L 9 is equipped with standard tyres sized 17.5x25.

What are the maneuverability specifications of the Sveloader L 9 wheel loader?

The Sveloader L 9 has an articulated-frame steering system and an outside turning radius of 4.7 meters.

What is the lifting force of the Sveloader L 9?

The Sveloader L 9 has a lifting force of 550 kN.

What is the maximum discharge height of the Sveloader L 9?

The Sveloader L 9 has a maximum discharge height of 2.7 meters.

What are the specifications of the primary work tool bucket on the Sveloader L 9?

The Sveloader L 9 has a bucket with a capacity of 1.6 cubic meters, a minimum bucket capacity of 1.6 cubic meters, and a bucket width of 2.6 meters.
