656D SEM 656D Specifications & Technical Data (2020—2026)

The SEM 656D is a wheel loader manufactured since 2020. It has a weight of 17.1 tons and a transport length of 8.396 meters. The b…

The SEM 656D is a wheel loader manufactured since 2020. It has a weight of 17.1 tons and a transport length of 8.396 meters. The bucket width is 2.963 meters and the maximum discharge height is 3.113 meters. It has a travel speed of 39 km/h and a transport width and height of 2.963 meters and 3.456 meters, respectively. The bucket capacity ranges from 2.7 to 4.5 cubic meters. Special equipment includes air conditioning.

656D

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 656D SEM

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.1 t

Standard tyres: 23.5-25

Bucket width: 2.963 m

Bucket capacity min.: 2.7 m³

Bucket capacity max.: 4.5 m³

Steering mode: KL

Transport length: 8.396 m

Transport width: 2.963 m

Transport height: 3.456 m

Travel speed: 39 km/h

Max. discharge height: 3.113 m

Engine manuf.: Cummins

Engine type: 6LTAA9.3

Engine power: 162 kW

Displacement: 9.242 l

Revolutions at max torque: 2000 rpm

More technical details, like: bucket capacity, turning radius outside, lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

656D SEM Specification for Europe (EN)

SEM 656D FAQ

When was the SEM 656D manufactured?

The SEM 656D was first produced in 2020.

How much does the SEM 656D weigh?

The SEM 656D weighs 17.1 tons.

What are the transport dimensions of the SEM 656D wheel loader?

The SEM 656D has a transport length of 8.4 meters, a transport width of 2.96 meters, and a transport height of 3.46 meters.

What is the travel speed of the SEM 656D wheel loader?

The SEM 656D has a travel speed of 39 km/h.

What is the standard tyre size of the SEM 656D wheel loader?

The SEM 656D wheel loader is equipped with standard tyres sized 23.5-25.

What is the steering mode of the SEM 656D?

The SEM 656D has articulated-frame steering.

What is the maximum discharge height of the SEM 656D wheel loader?

The SEM 656D wheel loader has a maximum discharge height of 3.11 meters.

What are the bucket specifications of the SEM 656D wheel loader?

The SEM 656D wheel loader has a bucket width of 2.96 meters with a capacity ranging from 2.7 to 4.5 cubic meters.
