618D SEM 618D Specifications & Technical Data (2020—2026)

The SEM 618D is a wheel loader manufactured since 2020. It has a weight of 5.94 tons and a transport length of 5.901 meters. The b…

The SEM 618D is a wheel loader manufactured since 2020. It has a weight of 5.94 tons and a transport length of 5.901 meters. The bucket width is 2 meters, and it has a maximum discharge height of 2.691 meters. The travel speed of the machine is 24 km/h. The transport width is 2 meters, and the transport height is 2.822 meters. The bucket capacity ranges from a maximum of 1 cubic meter to a minimum of 0.9 cubic meters.

618D

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 618D SEM

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.94 t

Standard tyres: 16/70-20

Bucket width: 2 m

Bucket capacity min.: 0.9 m³

Bucket capacity max.: 1 m³

Steering mode: KL

Transport length: 5.901 m

Transport width: 2 m

Transport height: 2.822 m

Travel speed: 24 km/h

Max. discharge height: 2.691 m

Engine manuf.: YTO

Engine type: YT4B4-22

Engine power: 60 kW

Displacement: 4.76 l

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity, turning radius outside, lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

618D SEM Specification for Europe (EN)

SEM 618D FAQ

When was the SEM 618D manufactured?

The SEM 618D was first produced in 2020.

How much does the SEM 618D wheel loader weigh?

The SEM 618D wheel loader weighs 5.94 tons.

What are the transport dimensions of the SEM 618D wheel loader?

The SEM 618D has a transport length of 5.9 meters, a transport width of 2 meters, and a transport height of 2.82 meters.

What is the travel speed of the SEM 618D wheel loader?

The SEM 618D wheel loader has a travel speed of 24 km/h.

What are the undercarriage specifications of the SEM 618D wheel loader?

The SEM 618D wheel loader is equipped with standard tyres sized 16/70-20.

What type of steering system does the SEM 618D wheel loader use?

The SEM 618D wheel loader uses an articulated-frame steering system.

What is the maximum discharge height of the SEM 618D wheel loader?

The SEM 618D wheel loader has a maximum discharge height of 2.69 meters.

What are the bucket specifications of the SEM 618D wheel loader?

The SEM 618D wheel loader has a bucket with a capacity ranging from 0.9 to 1 cubic meter and a width of 2 meters.

How much is a SEM 618D Wheel loader (2020u20132025) worth?

The residual value of the SEM 618D depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
