6680 Z Schäffer 6680 Z Specifications & Technical Data (2019—2021)

The Schäffer 6680 Z is a wheel loader manufactured from 2019 to 2021. It has a weight of 5.1 tons and a transport length of 4.725 …

The Schäffer 6680 Z is a wheel loader manufactured from 2019 to 2021. It has a weight of 5.1 tons and a transport length of 4.725 meters. The bucket capacity is 1 cubic meter with a width of 1.9 meters. The maximum discharge height is 2.7 meters. It has a travel speed of 20 km/h and a transport width of 1.71 meters. The transport height is 2.63 meters. The lifting force is 32.36 kN and it has a turning radius outside of 3.32 meters.

6680 Z

Years of manufacture: 2019—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 6680 Z Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.1 t

Standard tyres: 400/70-20 AS

Bucket width: 1.9 m

Bucket capacity: 1 m³

Steering mode: KL

Transport length: 4.725 m

Transport width: 1.71 m

Transport height: 2.63 m

Travel speed: 20 km/h

Max. discharge height: 2.7 m

Turning radius outside: 3.32 m

Lifting force: 32.36 kN

Engine manuf.: Deutz

Engine type: N/A

Engine power: 55 kW

No. of cylinders: 4

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 6680 Z FAQ

When was the Schu00e4ffer 6680 Z manufactured?

The Schu00e4ffer 6680 Z was manufactured from 2019 to 2021.

How much does the Schu00e4ffer 6680 Z wheel loader weigh?

The Schu00e4ffer 6680 Z wheel loader weighs 5.1 tons.

What are the transport dimensions of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z has a transport length of 4.73 meters, a transport width of 1.71 meters, and a transport height of 2.63 meters.

What is the travel speed of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z wheel loader is equipped with standard tyres sized 400/70-20 AS.

What are the maneuverability specifications of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z has an outside turning radius of 3.32 meters and uses articulated-frame steering.

What is the lifting force of the Schu0000e4ffer 6680 Z wheel loader?

The Schu0000e4ffer 6680 Z wheel loader has a lifting force of 32.36 kN.

What is the maximum discharge height of the Schu0000e4ffer 6680 Z?

The Schu0000e4ffer 6680 Z has a maximum discharge height of 2.7 meters.

What are the specifications of the primary work tool bucket on the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z wheel loader has a bucket with a capacity of 1 cubic meter and a width of 1.9 meters.

How much is a Schu00e4ffer 6680 Z Wheel loader (2019u20132021) worth?

The residual value of the Schu00e4ffer 6680 Z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
