6680 Z Schäffer 6680 Z Specifications & Technical Data (2016—2018)

The Schäffer 6680 Z is a wheel loader manufactured by Schäffer from 2016 to 2018. It has a weight of 5.1 tons and a transport leng…

The Schäffer 6680 Z is a wheel loader manufactured by Schäffer from 2016 to 2018. It has a weight of 5.1 tons and a transport length of 5.45 meters. The bucket capacity is 1 cubic meter with a width of 1.9 meters. The maximum discharge height is 2.7 meters and it has a travel speed of 20 km/h. The transport width is 1.59 meters and the transport height is 2.43 meters. The turning radius outside is 3.85 meters and the minimum bucket capacity is 1 cubic meter.

6680 Z

Years of manufacture: 2016—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 6680 Z Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.1 t

Standard tyres: 15.5/60-18 AS

Bucket width: 1.9 m

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Steering mode: KL

Transport length: 5.45 m

Transport width: 1.59 m

Transport height: 2.43 m

Travel speed: 20 km/h

Max. discharge height: 2.7 m

Turning radius outside: 3.85 m

Engine manuf.: Deutz

Engine type: k.A.

Engine power: 55 kW

Displacement: 3.6 l

No. of cylinders: 4

Emission level: Tier 3

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 6680 Z FAQ

When was the Schu00e4ffer 6680 Z manufactured?

The Schu00e4ffer 6680 Z was manufactured from 2016 to 2018.

How much does the Schu00e4ffer 6680 Z wheel loader weigh?

The Schu00e4ffer 6680 Z wheel loader weighs 5.1 tons.

What are the transport dimensions of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z has a transport length of 5.45 meters, a transport width of 1.59 meters, and a transport height of 2.43 meters.

What is the travel speed of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z wheel loader is equipped with standard tyres sized 15.5/60-18 AS.

What are the maneuverability specifications of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z has an articulated-frame steering system and an outside turning radius of 3.85 meters.

What is the maximum discharge height of the Schu0000e4ffer 6680 Z?

The Schu0000e4ffer 6680 Z has a maximum discharge height of 2.7 meters.

What are the bucket specifications of the Schu00e4ffer 6680 Z wheel loader?

The Schu00e4ffer 6680 Z wheel loader has a bucket capacity of 1 cubic meter, a minimum bucket capacity of 1 cubic meter, and a bucket width of 1.9 meters.
