5680 T Schäffer 5680 T Specifications & Technical Data (2019—2024)

The Schäffer 5680 T is a wheel loader manufactured since 2019. It has a weight of 4.84 tons and a transport length of 4.691 meters…

The Schäffer 5680 T is a wheel loader manufactured since 2019. It has a weight of 4.84 tons and a transport length of 4.691 meters. The maximum discharge height is 3.862 meters and it can travel at a speed of 20 km/h. The transport width is 1.7 meters and the transport height is 2.58 meters. It has a lifting force of 23.54 kN and a turning radius outside of 3.71 meters. Special equipment includes a telescopic feature.

5680 T

Years of manufacture: 2019—2024

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 5680 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.84 t

Standard tyres: 15.0/55-17 AS

Steering mode: KL

Transport length: 4.691 m

Transport width: 1.7 m

Transport height: 2.58 m

Travel speed: 20 km/h

Max. discharge height: 3.862 m

Turning radius outside: 3.71 m

Lifting force: 23.54 kN

Engine manuf.: Deutz

Engine type: TD2.9

Engine power: 55 kW

Displacement: 2.925 l

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 5680 T FAQ

When was the Schu00e4ffer 5680 T manufactured?

The Schu00e4ffer 5680 T was manufactured from 2019 to 2024.

How much does the Schu00e4ffer 5680 T wheel loader weigh?

The Schu00e4ffer 5680 T wheel loader weighs 4.84 tons.

What are the transport dimensions of the Schu00e4ffer 5680 T wheel loader?

The Schu00e4ffer 5680 T has a transport length of 4.69 meters, a transport width of 1.7 meters, and a transport height of 2.58 meters.

What is the travel speed of the Schu00e4ffer 5680 T wheel loader?

The Schu00e4ffer 5680 T wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 5680 T wheel loader?

The Schu00e4ffer 5680 T wheel loader is equipped with standard tyres sized 15.0/55-17 AS.

What are the maneuverability specifications of the Schu00e4ffer 5680 T wheel loader?

The Schu00e4ffer 5680 T has an outside turning radius of 3.71 meters and uses articulated-frame steering.

What is the lifting force of the Schu0000e4ffer 5680 T wheel loader?

The Schu0000e4ffer 5680 T wheel loader has a lifting force of 23.54 kN. No power rating data is available for this model.

What is the maximum discharge height of the Schu00e4ffer 5680 T wheel loader?

The Schu00e4ffer 5680 T wheel loader has a maximum discharge height of 3.86 meters.

How much is a Schu00e4ffer 5680 T Wheel loader (2019u20132024) worth?

The residual value of the Schu00e4ffer 5680 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
