4670 T-3 Schäffer 4670 T-3 Specifications & Technical Data (2025—2026)

Weight: 3.9t – Standard tyres: 15.0/55-17 AS, ET+45 – Steering mode: KL – Transport length: 4.93m – Transport width: 1.73m – Transport height: 2.27m

4670 T-3

Years of manufacture: 2025—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 4670 T-3 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.9 t

Standard tyres: 15.0/55-17 AS, ET+45

Steering mode: KL

Transport length: 4.93 m

Transport width: 1.73 m

Transport height: 2.27 m

Travel speed: 20 km/h

Max. discharge height: 3.48 m

Turning radius outside: 3.425 m

Engine manuf.: Kubota

Engine type: V2403-CR-T

Engine power: 48.6 kW

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 4670 T-3 FAQ

When was the Schu00e4ffer 4670 T-3 manufactured?

The Schu00e4ffer 4670 T-3 was first produced in 2025.

How much does the Schu00e4ffer 4670 T-3 wheel loader weigh?

The Schu00e4ffer 4670 T-3 wheel loader weighs 3.9 tons.

What are the transport dimensions of the Schu00e4ffer 4670 T-3 wheel loader?

The Schu00e4ffer 4670 T-3 has a transport length of 4.93 meters, a transport width of 1.73 meters, and a transport height of 2.27 meters.

What is the travel speed of the Schu00e4ffer 4670 T-3 wheel loader?

The Schu00e4ffer 4670 T-3 wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 4670 T-3 wheel loader?

The Schu00e4ffer 4670 T-3 is equipped with standard tyres sized 15.0/55-17 AS, ET+45.

What are the maneuverability specifications of the Schu00e4ffer 4670 T-3 wheel loader?

The Schu00e4ffer 4670 T-3 has an articulated-frame steering system and an outside turning radius of 3.425 meters.

What is the maximum discharge height of the Schu0000e4ffer 4670 T-3?

The Schu0000e4ffer 4670 T-3 has a maximum discharge height of 3.48 meters.

How much is a Schu00e4ffer 4670 T-3 Wheel loader (2025u20132025) worth?

The residual value of the Schu00e4ffer 4670 T-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
