2428-2 Schäffer 2428-2 Specifications & Technical Data (2021—2026)

The Schäffer 2428-2 is a wheel loader manufactured since 2021. It has a weight of 1.82 tons and a transport length of 3.03 meters.…

The Schäffer 2428-2 is a wheel loader manufactured since 2021. It has a weight of 1.82 tons and a transport length of 3.03 meters. The bucket capacity is 0.32 cubic meters with a width of 0.8 meters. The maximum discharge height is 1.45 meters. It has a travel speed of 15 km/h and a transport width of 1.25 meters. The transport height is 2.1 meters. The lifting force is 101.97 kN and the turning radius outside is 2.405 meters.

2428-2

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2428-2 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.82 t

Standard tyres: 27.8.50-15

Bucket width: 0.8 m

Bucket capacity: 0.32 m³

Steering mode: KL

Transport length: 3.03 m

Transport width: 1.25 m

Transport height: 2.1 m

Travel speed: 15 km/h

Max. discharge height: 1.45 m

Turning radius outside: 2.105 m

Lifting force: 101.97 kN

Engine manuf.: Kubota

Engine type: D1105

Engine power: 18.5 kW

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 2428-2 FAQ

When was the Schu00e4ffer 2428-2 manufactured?

The Schu00e4ffer 2428-2 was first produced in 2021.

How much does the Schu00e4ffer 2428-2 weigh?

The Schu00e4ffer 2428-2 weighs 1.82 tons.

What are the transport dimensions of the Schu00e4ffer 2428-2 wheel loader?

The Schu00e4ffer 2428-2 has a transport length of 3.03 meters, a transport width of 1.25 meters, and a transport height of 2.1 meters.

What is the travel speed of the Schu00e4ffer 2428-2 wheel loader?

The Schu00e4ffer 2428-2 wheel loader has a travel speed of 15 km/h.

What are the standard tyre specifications for the Schu00e4ffer 2428-2 wheel loader?

The Schu00e4ffer 2428-2 wheel loader is equipped with standard tyres sized 27.8.50-15.

What are the maneuverability specifications of the Schu00e4ffer 2428-2 wheel loader?

The Schu00e4ffer 2428-2 wheel loader has an articulated-frame steering system and an outside turning radius of 2.405 meters.

What is the power rating of the Schu0000e4ffer 2428-2 wheel loader?

The power rating data for the Schu0000e4ffer 2428-2 wheel loader is not available in the provided information.

What is the maximum discharge height of the Schu00e4ffer 2428-2?

The Schu00e4ffer 2428-2 has a maximum discharge height of 1.45 meters.

What are the bucket specifications of the Schu00e4ffer 2428-2 wheel loader?

The Schu00e4ffer 2428-2 wheel loader has a bucket capacity of 0.32 cubic meters and a bucket width of 0.8 meters.

How much is a Schu00e4ffer 2428-2 Wheel loader (2021u20132025) worth?

The residual value of the Schu00e4ffer 2428-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
