TL 80 Schaeff TL 80 Specifications & Technical Data (2017—2026)

The Schaeff TL 80 is a wheel loader manufactured since 2017. It has a weight of 4.9 tons and a transport length of 5.06 meters. Th…

The Schaeff TL 80 is a wheel loader manufactured since 2017. It has a weight of 4.9 tons and a transport length of 5.06 meters. The bucket capacity is 0.8 cubic meters with a bucket width of 1.85 meters. The maximum discharge height is 2.55 meters. It has a travel speed of 20 km/h and a transport width and height of 1.85 meters and 2.64 meters respectively. The lifting force of this machine is 48 kN. It has a turning radius outside of 4.16 meters. Additionally, it is equipped with a quick hitch mechanism.

TL 80

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TL 80 Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.9 t

Standard tyres: 405/70 R 18

Bucket width: 1.85 m

Bucket capacity: 0.8 m³

Steering mode: KL

Transport length: 5.06 m

Transport width: 1.85 m

Transport height: 2.64 m

Travel speed: 20 km/h

Max. discharge height: 2.55 m

Turning radius outside: 4.16 m

Lifting force: 48 kN

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 45 kW

Revolutions at max torque: 1600 rpm

Max. torque: 240 Nm

Emission level: Tier 4f

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Schaeff TL 80 FAQ

When was the Schaeff TL 80 manufactured?

The Schaeff TL 80 was first produced in 2017.

How much does the Schaeff TL 80 weigh?

The Schaeff TL 80 weighs 4.9 tons.

What are the transport dimensions of the Schaeff TL 80 wheel loader?

The Schaeff TL 80 has a transport length of 5.06 meters, a transport width of 1.85 meters, and a transport height of 2.64 meters.

What is the travel speed of the Schaeff TL 80 wheel loader?

The Schaeff TL 80 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schaeff TL 80 wheel loader?

The Schaeff TL 80 wheel loader is equipped with standard tyres sized 405/70 R 18.

What are the maneuverability specifications of the Schaeff TL 80 wheel loader?

The Schaeff TL 80 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.16 meters.

What is the power rating of the Schaeff TL 80 wheel loader?

The source data does not provide a power rating for the Schaeff TL 80 wheel loader.

What is the maximum discharge height of the Schaeff TL 80?

The Schaeff TL 80 has a maximum discharge height of 2.55 meters.

What are the bucket specifications of the Schaeff TL 80 wheel loader?

The Schaeff TL 80 wheel loader has a bucket capacity of 0.8 cubic meters and a bucket width of 1.85 meters.

How much is a Schaeff TL 80 Wheel loader (2017u20132025) worth?

The residual value of the Schaeff TL 80 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
