PT 192 Palazzani PT 192 Specifications & Technical Data (2013—2021)

Transmission

High-pressure, closed-loop hydrostatic transmission, with automatic adjustment of power, axial pistons pump and engine at variable displacement. Inching pedal control for traction regulation is modulating and integrated in the service brake pedal. Automatic working speed selection includes 4 forward and backward speeds: 2 working speeds and 2 transfer speeds with electronic controls at the joystick.

Axles

With epicycloids reduction on all four driving wheels, the front axle is rigid with an automatic proportional self-locking differential. The rear axle is oscillating with a total range steering of 25° and also features an automatic proportional self-locking differential.

Brakes

Duty brakes are equipped with hydraulic control on all four wheels, utilizing multiple disks under oil bath integrated in the axles, with 2 independent circuits. Parking brakes consist of an electro-hydraulic automatic negative brake, acting on both the front and rear axles.

Standard Equipment

Loader servo control Automatic proportional self-locking differential on front and rear axle Inching control on brake pedal (transmission speed regulation) Antipollution tank plugs Bucket with screwed teeth Reverse motion alarm Battery disconnecting switch Front and rear work lights Rotating lamp with magnetic fixing Shock absorbing and regulating “Deluxe” seat, with safety belt Regulating steering wheel Bucket electronic levelling Floating system Heating plant Air filter in aspiration from outside Rotofrom front mudguards Tool box Use and maintenance manual, spare parts catalogue Accessories for road circulation Italian road homologation for daily and night circulation CE Certification

Hydraulic System

Composed by: hydraulic gear pump, Modular distribution with main relief valve, double pump + fan-drive, shock proof, antivactuation valve and unloading valve for the secondary pump discharge. Pressurised circuit.

Steering

Servoassisted, with hydoguide and articulated chassis. Total steering angle of 80°. The hydraulic system is “Load Sensing” equipped, with valve on the primary pump.

Optional Equipment

Hydraulic quick bucket connection Universal forks Enlarged bucket Extra enlarged bucket for light material Enlarged bucket for light material having higher unloading 4-1 multipurpose bucket Paper and branches grab Bucket with side unloading Mixer bucket Wood grab Snow blade or snow plough Front rotating brush with bucket Teeth blade Asphalt concrete milling Inching control manually operated Electronic weighting system Air conditioning Radio Theft protection Ride control Floating element Empowered battery 12V 185 Ah
