PL 45.2 Palazzani PL 45.2 Specifications & Technical Data (2009—2010)

The Palazzani PL 45.2 is a wheel loader manufactured from 2009 to 2010. It has a weight of 4.7 tons and a transport length of 4.95…

The Palazzani PL 45.2 is a wheel loader manufactured from 2009 to 2010. It has a weight of 4.7 tons and a transport length of 4.95 meters. The bucket capacity is 0.75 cubic meters with a width of 1.9 meters. The maximum discharge height is 3.225 meters. It has a travel speed of 30 km/h and a transport width and height of 1.9 meters and 2.77 meters respectively. The turning radius outside is 4.25 meters. The minimum bucket capacity is also 0.75 cubic meters.

PL 45.2

Years of manufacture: 2009—2010

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PL 45.2 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.7 t

Standard tyres: 12.5x20

Bucket width: 1.9 m

Bucket capacity: 0.75 m³

Bucket capacity min.: 0.75 m³

Steering mode: KL

Transport length: 4.95 m

Transport width: 1.9 m

Transport height: 2.77 m

Travel speed: 30 km/h

Max. discharge height: 3.225 m

Turning radius outside: 4.25 m

Model series: PL

Engine manuf.: Perkins

Engine type: 804D-33T

Engine power: 65 kW

Displacement: 3.331 l

Revolutions at max torque: 2600 rpm

More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

PL 45.2 Palazzani Specification for Europe (EN)

Palazzani PL 45.2 FAQ

When was the Palazzani PL 45.2 manufactured?

The Palazzani PL 45.2 was manufactured from 2009 to 2010.

How much does the Palazzani PL 45.2 weigh?

The Palazzani PL 45.2 weighs 4.7 tons.

What are the transport dimensions of the Palazzani PL 45.2 wheel loader?

The Palazzani PL 45.2 has a transport length of 4.95 meters, a transport width of 1.9 meters, and a transport height of 2.77 meters.

What is the travel speed of the Palazzani PL 45.2 wheel loader?

The Palazzani PL 45.2 has a travel speed of 30 km/h.

What are the undercarriage tyre specifications of the Palazzani PL 45.2 wheel loader?

The Palazzani PL 45.2 wheel loader is equipped with standard tyres sized 12.5x20.

What are the maneuverability specifications of the Palazzani PL 45.2 wheel loader?

The Palazzani PL 45.2 has an articulated-frame steering system and an outside turning radius of 4.25 meters.

What is the material handling capacity of the Palazzani PL 45.2 in terms of maximum discharge height?

The Palazzani PL 45.2 has a maximum discharge height of 3.23 meters for material handling.

What are the specifications of the bucket on the Palazzani PL 45.2 wheel loader?

The Palazzani PL 45.2 wheel loader has a bucket capacity of 0.75 cubic meters, a minimum bucket capacity of 0.75 cubic meters, and a bucket width of 1.9 meters.

How much is a Palazzani PL 45.2 Wheel loader (2009u20132010) worth?

The residual value of the Palazzani PL 45.2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
