L 10.5 FT O&K L 10.5 FT Specifications & Technical Data (2003—2005)

The O&K L 10.5 FT Wheel Loader, manufactured from 2003 to 2005, weighs 5.7 tons and has a transport length of 5.545 meters. It fea…

The O&K L 10.5 FT Wheel Loader, manufactured from 2003 to 2005, weighs 5.7 tons and has a transport length of 5.545 meters. It features a bucket width of 2.1 meters and a maximum discharge height of 2.75 meters. With a travel speed of 35 km/h, it has a transport width of 2.02 meters and a transport height of 2.75 meters. The wheel loader has a lifting force of 58 kN and a minimum bucket capacity of 1.1 cubic meters.

L 10.5 FT

Years of manufacture: 2003—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 10.5 FT O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.7 t

Standard tyres: 405/70R20

Bucket width: 2.1 m

Bucket capacity min.: 1.1 m³

Transport length: 5.55 m

Transport width: 2.02 m

Transport height: 2.75 m

Travel speed: 35 km/h

Max. discharge height: 2.75 m

Lifting force: 58 kN

Model series: L

Engine manuf.: Perkins

Engine type: 1007.42

Engine power: 53 kW

Displacement: 4.23 l

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity, bucket capacity max., steering mode, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

L 10.5 FT O&K Specification for Europe (DE)

O&K L 10.5 FT FAQ

When was the O&K L 10.5 FT manufactured?

The O&K L 10.5 FT was manufactured from 2003 to 2005.

How much does the O&K L 10.5 FT wheel loader weigh?

The O&K L 10.5 FT wheel loader weighs 5.7 tons.

What are the transport dimensions of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT has a transport length of 5.55 meters, a transport width of 2.02 meters, and a transport height of 2.75 meters.

What is the travel speed of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT wheel loader has a travel speed of 35 km/h.

What are the undercarriage specifications of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT wheel loader is equipped with standard tyres sized 405/70R20.

What is the lifting force of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT wheel loader has a lifting force of 58 kN. The source data does not provide any power rating information.

What is the maximum discharge height of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT wheel loader has a maximum discharge height of 2.75 meters.

What are the bucket specifications of the O&K L 10.5 FT wheel loader?

The O&K L 10.5 FT wheel loader has a minimum bucket capacity of 1.1 cubic meters and a bucket width of 2.1 meters.
