W 190 New Holland W 190 Specifications & Technical Data (2006—2012)

The New Holland W 190 is a wheel loader manufactured by New Holland from 2006 to 2012. It has a weight of 17 tons and a bucket wid…

The New Holland W 190 is a wheel loader manufactured by New Holland from 2006 to 2012. It has a weight of 17 tons and a bucket width of 2 meters. The maximum discharge height is 4 meters, and it has a travel speed of 36 km/h. The transport width is 2 meters, and the transport height is 3 meters. The turning radius outside is 6 meters. The bucket capacity ranges from a minimum of 3 cubic meters to a maximum of 3 cubic meters. It is equipped with a diesel particulate filter.

W 190

Years of manufacture: 2006—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - W 190 New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.88 t

Standard tyres: 23.5 x 25

Bucket width: 2.96 m

Bucket capacity min.: 3.1 m³

Bucket capacity max.: 3.5 m³

Transport width: 2.76 m

Transport height: 3.436 m

Travel speed: 36.6 km/h

Max. discharge height: 4.073 m

Turning radius outside: 6.5 m

Engine manuf.: CNH

Engine type: NEF6CRTAA

Engine power: 155 kW

Displacement: 5.9 l

Revolutions at max torque: 1500 rpm

Max. torque: 860 Nm

No. of cylinders: 6

Cylinder bore x stroke: 102 x 120 mm

Emission level: Tier 2/Stage II

More technical details, like: bucket capacity, steering mode, transport length, lifting force, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

W 190 New Holland Specification for North America (EN)

New Holland W 190 FAQ

When was the New Holland W 190 manufactured?

The New Holland W 190 was manufactured from 2006 to 2012.

How much does the New Holland W 190 weigh?

The New Holland W 190 weighs 17.88 tons.

What are the transport dimensions of the New Holland W 190 wheel loader?

The New Holland W 190 has a transport width of 2.76 meters and a transport height of 3.44 meters.

What is the travel speed of the New Holland W 190 wheel loader?

The New Holland W 190 has a travel speed of 36.6 km/h.

What is the standard tyre size of the New Holland W 190 wheel loader's undercarriage?

The New Holland W 190 wheel loader has standard tyres sized 23.5 x 25.

What is the turning radius of the New Holland W 190 wheel loader?

The New Holland W 190 has an outside turning radius of 6.5 meters.

What is the maximum discharge height of the New Holland W 190?

The New Holland W 190 has a maximum discharge height of 4.07 meters.

What are the bucket specifications of the New Holland W 190 wheel loader?

The New Holland W 190 wheel loader has a bucket width of 2.96 meters, with a capacity ranging from 3.1 to 3.5 cubic meters.
