AX1000 Mecalac AX1000 Specifications & Technical Data (2020—2026)

The Mecalac AX1000 is a wheel loader manufactured since 2020. It has a weight of 5.41 tons and a transport length of 5.35 meters. …

The Mecalac AX1000 is a wheel loader manufactured since 2020. It has a weight of 5.41 tons and a transport length of 5.35 meters. The bucket capacity is 1 cubic meter, with a maximum discharge height of 2.71 meters. It has a travel speed of 20 km/h and a transport width of 1.85 meters. The transport height is 2.44 meters, and it has a lifting force of 43 kN. The bucket capacity ranges from 1 to 1.6 cubic meters, and it is equipped with a quick hitch hydraulic mechanism.

AX1000

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AX1000 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.41 t

Standard tyres: 365/70 R18

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Bucket capacity max.: 1.6 m³

Steering mode: KL

Transport length: 5.35 m

Transport width: 1.85 m

Transport height: 2.44 m

Travel speed: 30 km/h

Max. discharge height: 2.71 m

Lifting force: 43 kN

Model series: AX

Engine manuf.: Deutz

Engine type: TD2.9 L4 S5

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 260/1600 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AX1000 FAQ

When was the Mecalac AX1000 manufactured?

The Mecalac AX1000 was first produced in 2020.

How much does the Mecalac AX1000 wheel loader weigh?

The Mecalac AX1000 wheel loader weighs 5.41 tons.

What are the transport dimensions of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 has a transport length of 5.35 meters, a transport width of 1.85 meters, and a transport height of 2.44 meters.

What is the travel speed of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 has a travel speed of 30 km/h.

What are the undercarriage specifications of the Mecalac AX1000?

The Mecalac AX1000 is equipped with standard tyres sized 365/70 R18.

What is the steering mode of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 uses articulated-frame steering.

What are the power ratings of the Mecalac AX1000 wheel loader?

Power rating data for the Mecalac AX1000 wheel loader is not available in the provided information.

What is the maximum discharge height of the Mecalac AX1000?

The Mecalac AX1000 has a maximum discharge height of 2.71 meters.

What are the bucket capacity specifications of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 wheel loader has a bucket capacity of 1 cubic meter, with a minimum capacity of 1 cubic meter and a maximum capacity of 1.6 cubic meters.
