AX1000 Mecalac AX1000 Specifications & Technical Data (2015—2019)

The Mecalac AX1000 is a wheel loader manufactured from 2015 to 2019. It has a weight of 5.41 tons and a transport length of 5.35 m…

The Mecalac AX1000 is a wheel loader manufactured from 2015 to 2019. It has a weight of 5.41 tons and a transport length of 5.35 meters. The bucket capacity is 1 cubic meter, with a maximum discharge height of 2.71 meters. It has a travel speed of 20 km/h and a transport width of 1.85 meters. The transport height is 2.44 meters, and it has a lifting force of 43 kN. Special equipment includes a quick hitch hydraulic mechanism.

AX1000

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AX1000 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.41 t

Standard tyres: 365/70 R 18

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Steering mode: KL

Transport length: 5.35 m

Transport width: 1.85 m

Transport height: 2.44 m

Travel speed: 20 km/h

Max. discharge height: 2.71 m

Lifting force: 43 kN

Model series: AX

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Revolutions at max torque: 2600 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, bucket capacity max., turning radius outside, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AX1000 FAQ

When was the Mecalac AX1000 manufactured?

The Mecalac AX1000 was manufactured from 2015 to 2019.

How much does the Mecalac AX1000 wheel loader weigh?

The Mecalac AX1000 wheel loader weighs 5.41 tons.

What are the transport dimensions of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 has a transport length of 5.35 meters, a transport width of 1.85 meters, and a transport height of 2.44 meters.

What is the travel speed of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 wheel loader has standard tyres sized 365/70 R 18.

What is the steering mode of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 has articulated-frame steering.

What power ratings are available for the Mecalac AX1000?

The source data does not provide power ratings for the Mecalac AX1000. However, it specifies a lifting force of 43 kN.

What is the maximum discharge height of the Mecalac AX1000?

The Mecalac AX1000 has a maximum discharge height of 2.71 meters.

What is the bucket capacity of the Mecalac AX1000 wheel loader?

The Mecalac AX1000 wheel loader has a bucket capacity of 1 cubic meter.
