AX 1000 Mecalac AX 1000 Specifications & Technical Data (2012—2014)

The Mecalac AX 1000 is a wheel loader manufactured from 2012 to 2014. It has a weight of 5.8 tons and a transport length of 5.35 m…

The Mecalac AX 1000 is a wheel loader manufactured from 2012 to 2014. It has a weight of 5.8 tons and a transport length of 5.35 meters. The bucket capacity is 1 cubic meter, with a maximum discharge height of 2.86 meters. It has a travel speed of 30 km/h and a transport width of 1.85 meters. The transport height is 2.45 meters, and it has a lifting force of 44.5 kN. Special equipment includes a quick hitch hydraulic mechanism.

AX 1000

Years of manufacture: 2012—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AX 1000 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.8 t

Standard tyres: 365/70R18

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Steering mode: KL

Transport length: 5.35 m

Transport width: 1.85 m

Transport height: 2.45 m

Travel speed: 30 km/h

Max. discharge height: 2.86 m

Lifting force: 44.5 kN

Model series: AX

Engine manuf.: John Deere

Engine type: 4024HF295

Engine power: 49 kW

Revolutions at max torque: 2000 rpm

More technical details, like: bucket width, bucket capacity max., turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AX 1000 FAQ

When was the Mecalac AX 1000 manufactured?

The Mecalac AX 1000 was manufactured from 2012 to 2014.

How much does the Mecalac AX 1000 weigh?

The Mecalac AX 1000 weighs 5.8 tons.

What are the transport dimensions of the Mecalac AX 1000 wheel loader?

The Mecalac AX 1000 has a transport length of 5.35 meters, a transport width of 1.85 meters, and a transport height of 2.45 meters.

What is the travel speed of the Mecalac AX 1000 wheel loader?

The Mecalac AX 1000 has a travel speed of 30 km/h.

What are the standard tyre specifications for the Mecalac AX 1000 wheel loader?

The Mecalac AX 1000 wheel loader comes with standard tyres sized 365/70R18.

What is the steering mode of the Mecalac AX 1000?

The Mecalac AX 1000 has articulated-frame steering.

What is the lifting force of the Mecalac AX 1000 wheel loader?

The Mecalac AX 1000 wheel loader has a lifting force of 44.5 kN.

What is the maximum discharge height of the Mecalac AX 1000?

The Mecalac AX 1000 has a maximum discharge height of 2.86 meters.

What is the bucket capacity of the Mecalac AX 1000 wheel loader?

The Mecalac AX 1000 wheel loader has a bucket capacity of 1 cubic meter.
