AS600 Mecalac AS600 Specifications & Technical Data (2018—2026)

The Mecalac AS600 is a wheel loader manufactured since 2018. It has a weight of 4.4 tons and a transport length of 4.95 meters. Th…

The Mecalac AS600 is a wheel loader manufactured since 2018. It has a weight of 4.4 tons and a transport length of 4.95 meters. The bucket capacity is 0.6 cubic meters with a width of 1.7 meters. The maximum discharge height is 2.57 meters. It has a travel speed of 30 km/h and a transport width of 1.68 meters. The transport height is 2.49 meters. The lifting force is 17.3 kN. The turning radius outside is 3.185 meters. The bucket capacity ranges from 0.6 to 0.8 cubic meters. It is equipped with a swing loader.

AS600

Years of manufacture: 2018—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS600 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.4 t

Standard tyres: 12.5/80-18

Bucket width: 1.7 m

Bucket capacity: 0.6 m³

Bucket capacity min.: 0.6 m³

Bucket capacity max.: 0.8 m³

Steering mode: AL

Transport length: 4.95 m

Transport width: 1.68 m

Transport height: 2.49 m

Travel speed: 30 km/h

Max. discharge height: 2.57 m

Turning radius outside: 3.185 m

Lifting force: 17.3 kN

Model series: AS

Engine manuf.: Deutz

Engine type: TCD2.2 L3

Engine power: 36.4 kW

Displacement: 2.2 l

Revolutions at max torque: 2300 rpm

Max. torque: 180/1600 Nm

No. of cylinders: 3

Emission level: V

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS600 FAQ

When was the Mecalac AS600 manufactured?

The Mecalac AS600 was first produced in 2018.

How much does the Mecalac AS600 wheel loader weigh?

The Mecalac AS600 wheel loader weighs 4.4 tons.

What are the transport dimensions of the Mecalac AS600 wheel loader?

The Mecalac AS600 has a transport length of 4.95 meters, a transport width of 1.68 meters, and a transport height of 2.49 meters.

What is the travel speed of the Mecalac AS600 wheel loader?

The Mecalac AS600 has a travel speed of 30 km/h.

What are the standard tyres of the Mecalac AS600 wheel loader's undercarriage?

The Mecalac AS600 wheel loader is equipped with standard tyres sized 12.5/80-18.

What are the maneuverability specifications of the Mecalac AS600 wheel loader?

The Mecalac AS600 has an outside turning radius of 3.185 meters and features all-wheel steering.

What is the power rating of the Mecalac AS600 wheel loader?

There is no power rating data available for the Mecalac AS600 wheel loader. However, it has a lifting force of 17.3 kN.

What is the maximum discharge height of the Mecalac AS600?

The Mecalac AS600 has a maximum discharge height of 2.57 meters.

What are the specifications of the bucket on the Mecalac AS600 wheel loader?

The Mecalac AS600 wheel loader has a bucket with a capacity ranging from 0.6 to 0.8 cubic meters and a width of 1.7 meters.
