AF1050 Mecalac AF1050 Specifications & Technical Data (2016—2020)

The Mecalac AF1050 is a wheel loader manufactured from 2016 to 2020. It has a weight of 5.8 tons and a transport length of 6.03 me…

The Mecalac AF1050 is a wheel loader manufactured from 2016 to 2020. It has a weight of 5.8 tons and a transport length of 6.03 meters. The bucket capacity is 1.05 cubic meters, with a maximum discharge height of 2.7 meters. It has a travel speed of 30 km/h and a transport width of 2.1 meters. The transport height is 2.83 meters. The lifting force of this machine is 65 kN. It is equipped with a quick hitch hydr. for special operations.

AF1050

Years of manufacture: 2016—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AF1050 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.8 t

Standard tyres: 14.5-20

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Steering mode: AL

Transport length: 6.03 m

Transport width: 2.1 m

Transport height: 2.83 m

Travel speed: 30 km/h

Max. discharge height: 2.7 m

Lifting force: 65 kN

Model series: AF

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Revolutions at max torque: 2600 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, bucket capacity max., turning radius outside, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AF1050 FAQ

When was the Mecalac AF1050 manufactured?

The Mecalac AF1050 was manufactured from 2016 to 2020.

How much does the Mecalac AF1050 weigh?

The Mecalac AF1050 weighs 5.8 tons.

What are the transport dimensions of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 has a transport length of 6.03 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 has a travel speed of 30 km/h.

What is the standard tyre size of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 wheel loader has standard tyres sized 14.5-20.

What is the steering mode of the Mecalac AF1050?

The Mecalac AF1050 has an all-wheel steering mode.

What is the lifting force of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 wheel loader has a lifting force of 65 kN. The source data does not provide power ratings for this machine.

What is the maximum discharge height of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 wheel loader has a maximum discharge height of 2.7 meters.

What is the bucket capacity of the Mecalac AF1050 wheel loader?

The Mecalac AF1050 wheel loader has a bucket capacity of 1.05 cubic meters.
