MLA 2-25 H Manitou MLA 2-25 H Specifications & Technical Data (2022—2026)

The Manitou MLA 2-25 H is a wheel loader manufactured since 2022. It has a weight of 1.74 tons and a transport length of 2.928 met…

The Manitou MLA 2-25 H is a wheel loader manufactured since 2022. It has a weight of 1.74 tons and a transport length of 2.928 meters. The bucket width is 1.1 meters and the maximum discharge height is 2.008 meters. It has a travel speed of 12 km/h and a transport width of 1.04 meters. The transport height is 2.14 meters, and the turning radius outside is 2.251 meters.

Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H
Wheel Loaders Manitou MLA 2-25 H

Visit Manitou live at

Technical specs - MLA 2-25 H Manitou

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.74 t
Bucket width
1.1 m
Steering mode
KL
Transport length
2.928 m
Transport width
1.04 m
Transport height
2.14 m
Travel speed
12 km/h
Max. discharge height
2.008 m
Turning radius outside
2.251 m
Engine manuf.
Perkins
Engine type
403J-11
Engine power
18.4 kW
Max. torque
66.8/1200 Nm
No. of cylinders
3
Emission level
V

More technical details, like: standard tyres, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Manitou MLA 2-25 H FAQ

When was the Manitou MLA 2-25 H manufactured?

The Manitou MLA 2-25 H was first produced in 2022.

How much does the Manitou MLA 2-25 H wheel loader weigh?

The Manitou MLA 2-25 H wheel loader weighs 1.74 tons.

What are the transport dimensions of the Manitou MLA 2-25 H wheel loader?

The Manitou MLA 2-25 H has a transport length of 2.93 meters, a transport width of 1.04 meters, and a transport height of 2.14 meters.

What is the travel speed of the Manitou MLA 2-25 H wheel loader?

The Manitou MLA 2-25 H has a travel speed of 12 km/h.

What are the maneuverability specifications of the Manitou MLA 2-25 H wheel loader?

The Manitou MLA 2-25 H has an articulated-frame steering system and an outside turning radius of 2.251 meters.

What is the maximum discharge height of the Manitou MLA 2-25 H wheel loader?

The Manitou MLA 2-25 H has a maximum discharge height of 2.01 meters.

What is the bucket width of the Manitou MLA 2-25 H wheel loader?

The bucket width of the Manitou MLA 2-25 H wheel loader is 1.1 meters.

How much is a Manitou MLA 2-25 H Wheel loader (2022u20132025) worth?

The residual value of the Manitou MLA 2-25 H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
