ZL50CNX Liugong ZL50CNX Specifications & Technical Data (2014—2019)

The Liugong ZL50CNX is a wheel loader manufactured by Liugong from 2014 to 2019. It has a weight of 16.7 tons and a transport leng…

The Liugong ZL50CNX is a wheel loader manufactured by Liugong from 2014 to 2019. It has a weight of 16.7 tons and a transport length of 8.03 meters. The bucket capacity is 3 cubic meters, and it has a maximum discharge height of 2.97 meters. The travel speed of this wheel loader is 40 km/h, and its transport width is 2.75 meters. The transport height is 3.47 meters, and it has a lifting force of 167 kN. The turning radius outside is 6.647 meters. Additionally, it is equipped with air conditioning.

Wheel Loaders Liugong ZL50CNX

Visit Liugong live at

Technical specs - ZL50CNX Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.7 t
Standard tyres
23.5-25
Bucket capacity
3 m³
Bucket capacity min.
3 m³
Transport length
8.03 m
Transport width
2.75 m
Transport height
3.47 m
Travel speed
40 km/h
Max. discharge height
2.97 m
Turning radius outside
6.647 m
Lifting force
167 kN
Engine manuf.
Cummins
Engine type
6LT9.3
Engine power
148 kW
Displacement
9.3 l
Revolutions at max torque
2200 rpm
Max. torque
890 Nm
No. of cylinders
6
Emission level
Tier 2/EU II

More technical details, like: bucket width, bucket capacity max., steering mode, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liugong ZL50CNX FAQ

When was the Liugong ZL50CNX manufactured?

The Liugong ZL50CNX was manufactured from 2014 to 2019.

How much does the Liugong ZL50CNX wheel loader weigh?

The Liugong ZL50CNX wheel loader weighs 16.7 tons.

What are the transport dimensions of the Liugong ZL50CNX wheel loader?

The Liugong ZL50CNX has a transport length of 8.03 meters, a transport width of 2.75 meters, and a transport height of 3.47 meters.

What is the travel speed of the Liugong ZL50CNX wheel loader?

The Liugong ZL50CNX wheel loader has a travel speed of 40 km/h.

What are the standard tyre specifications of the Liugong ZL50CNX wheel loader?

The Liugong ZL50CNX wheel loader has standard tyres sized 23.5-25.

What is the outside turning radius of the Liugong ZL50CNX wheel loader?

The Liugong ZL50CNX has an outside turning radius of 6.647 meters.

What is the power rating of the Liugong ZL50CNX wheel loader?

The available data does not provide a power rating for the Liugong ZL50CNX wheel loader.

What is the maximum discharge height of the Liugong ZL50CNX?

The Liugong ZL50CNX has a maximum discharge height of 2.97 meters.

What is the bucket capacity of the Liugong ZL50CNX wheel loader?

The Liugong ZL50CNX wheel loader has a bucket capacity of 3 cubic meters.

How much is a Liugong ZL50CNX Wheel loader (2014u20132019) worth?

The residual value of the Liugong ZL50CNX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
