L 580 2+2 Liebherr L 580 2+2 Specifications & Technical Data (2006—2026)

The Liebherr L 580 2+2 is a wheel loader manufactured since 2006. It has a weight of 24.58 tons and a transport length of 9.57 met…

The Liebherr L 580 2+2 is a wheel loader manufactured since 2006. It has a weight of 24.58 tons and a transport length of 9.57 meters. The bucket capacity is 5 cubic meters with a width of 3.3 meters. The maximum discharge height is 6.42 meters. It has a travel speed of 40 km/h and a transport width and height of 3.3 meters and 3.55 meters respectively. The lifting force is 250 kN and it has a turning radius outside of 7.45 meters.

Wheel Loaders Liebherr L 580 2+2

Visit Liebherr live at

Technical specs - L 580 2+2 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
24.58 t
Standard tyres
26.5 R25
Bucket width
3.3 m
Bucket capacity
5 m³
Transport length
9.57 m
Transport width
3.3 m
Transport height
3.55 m
Travel speed
40 km/h
Max. discharge height
6.42 m
Turning radius outside
7.45 m
Lifting force
250 kN
Model series
L
Engine manuf.
Liebherr
Engine type
D936L A6
Engine power
200 kW
Displacement
10.52 l
Revolutions at max torque
2000 rpm
Max. torque
1270 Nm
No. of cylinders
6
Cylinder bore x stroke
122x150 mm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 580 2+2 FAQ

When was the Liebherr L 580 2+2 manufactured?

The Liebherr L 580 2+2 was first produced in 2006.

How much does the Liebherr L 580 2+2 weigh?

The Liebherr L 580 2+2 weighs 24.58 tons.

What are the transport dimensions of the Liebherr L 580 2+2 wheel loader?

The Liebherr L 580 2+2 has a transport length of 9.57 meters, a transport width of 3.3 meters, and a transport height of 3.55 meters.

What is the travel speed of the Liebherr L 580 2+2 wheel loader?

The Liebherr L 580 2+2 has a travel speed of 40 km/h.

What are the standard tyre specifications of the Liebherr L 580 2+2 wheel loader's undercarriage?

The Liebherr L 580 2+2 wheel loader has standard tyres sized 26.5 R25.

What is the turning radius of the Liebherr L 580 2+2 wheel loader?

The Liebherr L 580 2+2 has an outside turning radius of 7.45 meters.

What is the lifting force of the Liebherr L 580 2+2 wheel loader, given that no power ratings are provided?

The Liebherr L 580 2+2 wheel loader has a lifting force of 250 kN; no power ratings are provided in the available data.

What is the material handling capacity of the Liebherr L 580 2+2 in terms of maximum discharge height?

The Liebherr L 580 2+2 has a maximum discharge height of 6.42 meters.

What are the specifications of the bucket on the Liebherr L 580 2+2 wheel loader?

The bucket of the Liebherr L 580 2+2 has a capacity of 5 cubic meters and a width of 3.3 meters.

How much is a Liebherr L 580 2+2 Wheel loader (2006u20132025) worth?

The residual value of the Liebherr L 580 2+2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
