Liebherr L 576 2+2 Specifications & Technical Data (2006-2024)

Rate this machine now!

The Liebherr L 576 2+2 is a wheel loader manufactured since 2006. It has a weight of 24.26 tons and a transport length of 9.45 met... Read more

The Liebherr L 576 2+2 is a wheel loader manufactured since 2006. It has a weight of 24.26 tons and a transport length of 9.45 meters. The bucket capacity is 4.5 cubic meters with a width of 3 meters. The maximum discharge height is 6.04 meters. It has a travel speed of 40 km/h and a transport width and height of 3 meters and 3.55 meters respectively. The lifting force is 264 kN and it has a turning radius outside of 7.145 meters.

Technical specs - L 576 2+2 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 24.26 t
  • Standard tyres 26.5 R25
  • Bucket width 3 m
  • Bucket capacity 4.5 m³
  • Transport length 9.45 m
  • Transport width 3 m
  • Transport height 3.55 m
  • Travel speed 40 km/h
  • Max. discharge height 6.04 m
  • Turning radius outside 7.145 m
  • Lifting force 264 kN
  • Model series L
  • Engine manuf. Liebherr
  • Engine type D936L A6
  • Engine power 200 kW
  • Displacement 10.52 l
  • Revolutions at max torque 2000 rpm
  • Max. torque 1270 Nm
  • No. of cylinders 6
  • Cylinder bore x stroke 122x150 mm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

  • Diesel particulate filter
  • Swing loader
  • telescopic
  • Aircondition
  • Quick hitch hydr.
  • Quick hitch mech.
