L 566 Liebherr L 566 Specifications & Technical Data (2006—2012)

Model rating
7,75 / 10

The Liebherr L 566 is a wheel loader manufactured from 2006 to 2012. It has a weight of 22.5 tons and a transport length of 9 mete…

The Liebherr L 566 is a wheel loader manufactured from 2006 to 2012. It has a weight of 22.5 tons and a transport length of 9 meters. The bucket capacity is 4 cubic meters, with a bucket width of 3 meters. The maximum discharge height is 3.24 meters, and it has a travel speed of 40 km/h. The transport width is 3 meters, and the transport height is 3.55 meters. It has a lifting force of 264 kN and a turning radius outside of 7.1 meters. Special equipment includes air conditioning.

Wheel Loaders Liebherr L 566
Wheel Loaders Liebherr L 566
Wheel Loaders Liebherr L 566
Wheel Loaders Liebherr L 566

Visit Liebherr live at

Technical specs - L 566 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.5 t
Standard tyres
26.5 R 25
Bucket width
3 m
Bucket capacity
4 m³
Bucket capacity min.
4 m³
Steering mode
KL
Transport length
9 m
Transport width
3 m
Transport height
3.55 m
Travel speed
40 km/h
Max. discharge height
3.24 m
Turning radius outside
7.1 m
Lifting force
264 kN
Model series
L
Engine manuf.
Liebherr
Engine type
D 936 LA 6
Engine power
190 kW
Displacement
10.52 l
Revolutions at max torque
1300 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 566 FAQ

When was the Liebherr L 566 manufactured?

The Liebherr L 566 was manufactured from 2006 to 2012.

How much does the Liebherr L 566 weigh?

The Liebherr L 566 weighs 22.5 tons.

What are the transport dimensions of the Liebherr L 566 wheel loader?

The Liebherr L 566 has a transport length of 9 meters, a transport width of 3 meters, and a transport height of 3.55 meters.

What is the travel speed of the Liebherr L 566 wheel loader?

The Liebherr L 566 has a travel speed of 40 km/h.

What are the undercarriage tyre specifications of the Liebherr L 566 wheel loader?

The Liebherr L 566 wheel loader is equipped with standard tyres sized 26.5 R 25.

What are the maneuverability specifications of the Liebherr L 566 wheel loader?

The Liebherr L 566 wheel loader has an outside turning radius of 7.1 meters and features articulated-frame steering.

What power ratings are available for the Liebherr L 566 wheel loader?

The source data does not provide any power ratings for the Liebherr L 566 wheel loader.

What is the maximum discharge height of the Liebherr L 566?

The Liebherr L 566 has a maximum discharge height of 3.24 meters.

What are the specifications of the bucket on the Liebherr L 566 wheel loader?

The Liebherr L 566 wheel loader has a bucket capacity of 4 cubic meters, a minimum bucket capacity of 4 cubic meters, and a bucket width of 3 meters.

How much is a Liebherr L 566 Wheel loader (2006u20132012) worth?

The residual value of the Liebherr L 566 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating
7,75 / 10
Quotation mark

Liebherr L 566 user from South Africa

Fuel efficient reliable

Quotation mark

Liebherr L 566 user from Macedonia

Very good machine. Good engine . Good hydraulic system. Everything is perfect.
