8155L Kramer 8155L Specifications & Technical Data (2021—2026)

The Kramer 8155L is a wheel loader manufactured by Kramer since 2021. It has a weight of 10.25 tons and a transport length of 7.04…

The Kramer 8155L is a wheel loader manufactured by Kramer since 2021. It has a weight of 10.25 tons and a transport length of 7.04 meters. The bucket capacity is 1.45 cubic meters, with a bucket width of 2.5 meters. The maximum discharge height is 3.165 meters. It has a travel speed of 20 km/h and a transport width of 2.5 meters. The transport height is 3.01 meters. The lifting force is 68 kN, and the turning radius outside is 3.865 meters. The bucket capacity ranges from a minimum of 1.35 cubic meters to a maximum of 3.5 cubic meters. It is equipped with air conditioning, a diesel particulate filter, and a quick hitch hydraulic system.

8155L

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 8155L Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.25 t

Standard tyres: 500/70R24

Bucket width: 2.5 m

Bucket capacity: 1.45 m³

Bucket capacity min.: 1.35 m³

Bucket capacity max.: 3.5 m³

Steering mode: AL

Transport length: 7.04 m

Transport width: 2.5 m

Transport height: 3.01 m

Travel speed: 20 km/h

Max. discharge height: 3.165 m

Turning radius outside: 3.865 m

Lifting force: 68 kN

Engine manuf.: Deutz

Engine type: TCD 3.6

Engine power: 100 kW

Displacement: 3.621 l

Max. torque: 500/1600 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer 8155L FAQ

When was the Kramer 8155L manufactured?

The Kramer 8155L was first produced in 2021.

How much does the Kramer 8155L wheel loader weigh?

The Kramer 8155L wheel loader weighs 10.25 tons.

What are the transport dimensions of the Kramer 8155L wheel loader?

The Kramer 8155L has a transport length of 7.04 meters, a transport width of 2.5 meters, and a transport height of 3.01 meters.

What is the travel speed of the Kramer 8155L wheel loader?

The Kramer 8155L has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Kramer 8155L wheel loader?

The Kramer 8155L wheel loader is equipped with standard tyres sized 500/70R24.

What are the maneuverability specifications of the Kramer 8155L wheel loader?

The Kramer 8155L wheel loader has an outside turning radius of 3.865 meters and features all-wheel steering.

What is the power rating of the Kramer 8155L wheel loader?

The source data does not provide the power rating for the Kramer 8155L wheel loader.

What is the material handling capacity of the Kramer 8155L in terms of discharge height?

The Kramer 8155L has a maximum discharge height of 3.17 meters.

What are the specifications of the bucket on the Kramer 8155L wheel loader?

The Kramer 8155L wheel loader has a bucket capacity ranging from 1.35 to 3.5 cubic meters, with a standard capacity of 1.45 cubic meters and a bucket width of 2.5 meters.

How much is a Kramer 8155L Wheel loader (2021u20132025) worth?

The residual value of the Kramer 8155L depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
