8095 Kramer 8095 Specifications & Technical Data (2024—2026)

Weight: 5.3t – Standard tyres: 12.5–20 – Bucket width: 2.05m – Bucket capacity: 0.95m³ – Steering mode: AL – Transport length: 5.26m

8095

Years of manufacture: 2024—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 8095 Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.3 t

Standard tyres: 12.5–20

Bucket width: 2.05 m

Bucket capacity: 0.95 m³

Steering mode: AL

Transport length: 5.26 m

Transport width: 1.78 m

Transport height: 2.49 m

Travel speed: 20 km/h

Max. discharge height: 2.68 m

Turning radius outside: 2.84 m

Lifting force: 42.8 kN

Engine manuf.: Deutz

Engine type: TCD2.9

Engine power: 55.4 kW

Displacement: 2.924 l

Max. torque: 300/1600 Nm

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer 8095 FAQ

When was the Kramer 8095 manufactured?

The Kramer 8095 was first produced in 2024.

How much does the Kramer 8095 wheel loader weigh?

The Kramer 8095 wheel loader weighs 5.3 tons.

What are the transport dimensions of the Kramer 8095 wheel loader?

The Kramer 8095 has a transport length of 5.26 meters, a transport width of 1.78 meters, and a transport height of 2.49 meters.

What is the travel speed of the Kramer 8095 wheel loader?

The Kramer 8095 wheel loader has a travel speed of 20 km/h.

What is the standard tyre size of the Kramer 8095 wheel loader?

The Kramer 8095 wheel loader has standard tyres of size 12.5u000320.

What are the maneuverability specifications of the Kramer 8095 wheel loader?

The Kramer 8095 wheel loader has an outside turning radius of 2.84 meters and features all-wheel steering.

What is the lifting force of the Kramer 8095 wheel loader?

The Kramer 8095 wheel loader has a lifting force of 42.8 kN.

What is the maximum discharge height of the Kramer 8095?

The Kramer 8095 has a maximum discharge height of 2.68 meters.

What are the specifications of the bucket on the Kramer 8095 wheel loader?

The Kramer 8095 wheel loader has a bucket with a capacity of 0.95 cubic meters and a width of 2.05 meters.
