5085L Kramer 5085L Specifications & Technical Data (2019—2026)

The Kramer 5085L is a wheel loader manufactured by Kramer since 2019. It has a weight of 5 tons and a transport length of 5.6 mete…

The Kramer 5085L is a wheel loader manufactured by Kramer since 2019. It has a weight of 5 tons and a transport length of 5.6 meters. The bucket capacity is 0.85 cubic meters with a width of 1.95 meters. The maximum discharge height is 2.82 meters. It has a travel speed of 20 km/h and a transport width of 1.74 meters. The transport height is 2.48 meters. The lifting force is 44.4 kN and the turning radius outside is 2.84 meters. The machine is equipped with a diesel particulate filter and a quick hitch hydr. The maximum bucket capacity is 1.5 cubic meters and the minimum is 0.75 cubic meters.

Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L
Wheel Loaders Kramer 5085L

Technical specs - 5085L Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5 t
Standard tyres
12.5–20
Bucket width
1.95 m
Bucket capacity
0.85 m³
Bucket capacity min.
0.75 m³
Bucket capacity max.
1.5 m³
Steering mode
AL
Transport length
5.6 m
Transport width
1.74 m
Transport height
2.48 m
Travel speed
20 km/h
Max. discharge height
2.82 m
Turning radius outside
2.84 m
Lifting force
44.4 kN
Engine manuf.
Kohler
Engine type
KDI2504TCR
Engine power
55.4 kW
Displacement
2.482 l
Max. torque
300/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
88x102 mm
Emission level
V

More technical details, like: model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kramer 5085L FAQ

When was the Kramer 5085L manufactured?

The Kramer 5085L was first produced in 2019.

How much does the Kramer 5085L weigh?

The Kramer 5085L weighs 5 tons.

What are the transport dimensions of the Kramer 5085L wheel loader?

The Kramer 5085L has a transport length of 5.6 meters, a transport width of 1.74 meters, and a transport height of 2.48 meters.

What is the travel speed of the Kramer 5085L wheel loader?

The Kramer 5085L has a travel speed of 20 km/h.

What are the undercarriage specifications of the Kramer 5085L wheel loader?

The Kramer 5085L wheel loader has standard tyres sized 12.5u001320.

What are the maneuverability specifications of the Kramer 5085L?

The Kramer 5085L has an outside turning radius of 2.84 meters and features all-wheel steering.

What is the lifting force of the Kramer 5085L wheel loader?

The Kramer 5085L wheel loader has a lifting force of 44.4 kN.

What is the maximum discharge height of the Kramer 5085L?

The Kramer 5085L has a maximum discharge height of 2.82 meters.

What are the bucket specifications of the Kramer 5085L wheel loader?

The Kramer 5085L wheel loader has a bucket capacity of 0.85 cubic meters, with a maximum capacity of 1.5 cubic meters and a minimum capacity of 0.75 cubic meters, and the bucket width is 1.95 meters.

How much is a Kramer 5085L Wheel loader (2019u20132025) worth?

The residual value of the Kramer 5085L depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
