5085 Kramer 5085 Specifications & Technical Data (2019—2026)

The Kramer 5085 is a wheel loader manufactured by Kramer since 2019. It has a weight of 5 tons and a transport length of 5.27 mete…

The Kramer 5085 is a wheel loader manufactured by Kramer since 2019. It has a weight of 5 tons and a transport length of 5.27 meters. The bucket capacity is 0.85 cubic meters with a width of 1.95 meters. The maximum discharge height is 2.53 meters and it has a travel speed of 20 km/h. The transport width is 1.74 meters and the transport height is 2.48 meters. It has a lifting force of 42.9 kN and a turning radius outside of 2.84 meters. The bucket capacity ranges from 0.75 to 1.5 cubic meters. It is equipped with a diesel particulate filter and a quick hitch hydr.

Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085
Wheel Loaders Kramer 5085

Technical specs - 5085 Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5 t
Standard tyres
12.5–20
Bucket width
1.95 m
Bucket capacity
0.85 m³
Bucket capacity min.
0.75 m³
Bucket capacity max.
1.5 m³
Steering mode
AL
Transport length
5.27 m
Transport width
1.74 m
Transport height
2.48 m
Travel speed
20 km/h
Max. discharge height
2.53 m
Turning radius outside
2.84 m
Lifting force
42.9 kN
Engine manuf.
Kohler
Engine type
KDI2504TCR
Engine power
55.4 kW
Displacement
2.482 l
Max. torque
300/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
88x102 mm
Emission level
V

More technical details, like: model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kramer 5085 FAQ

When was the Kramer 5085 manufactured?

The Kramer 5085 was first produced in 2019.

How much does the Kramer 5085 wheel loader weigh?

The Kramer 5085 wheel loader weighs 5 tons.

What are the transport dimensions of the Kramer 5085 wheel loader?

The Kramer 5085 has a transport length of 5.27 meters, a transport width of 1.74 meters, and a transport height of 2.48 meters.

What is the travel speed of the Kramer 5085 wheel loader?

The Kramer 5085 has a travel speed of 20 km/h.

What is the standard tyre size of the Kramer 5085 wheel loader?

The Kramer 5085 wheel loader has standard tyres sized 12.5u201320.

What are the maneuverability specifications of the Kramer 5085 wheel loader?

The Kramer 5085 wheel loader has an outside turning radius of 2.84 meters and features all-wheel steering.

What is the power rating of the Kramer 5085 wheel loader?

The available data does not provide a power rating for the Kramer 5085 wheel loader.

What is the maximum discharge height of the Kramer 5085?

The Kramer 5085 has a maximum discharge height of 2.53 meters.

What are the specifications of the bucket on the Kramer 5085 wheel loader?

The Kramer 5085 wheel loader has a bucket with a capacity ranging from 0.75 to 1.5 cubic meters, a nominal capacity of 0.85 cubic meters, and a width of 1.95 meters.

How much is a Kramer 5085 Wheel loader (2019u20132025) worth?

The residual value of the Kramer 5085 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
