Technical specs - 5075L Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.4 t
- Standard tyres
- 12.5-18
- Bucket width
- 1.85 m
- Bucket capacity
- 0.75 m³
- Bucket capacity min.
- 0.75 m³
- Bucket capacity max.
- 1.5 m³
- Steering mode
- AL
- Transport length
- 5.18 m
- Transport width
- 1.74 m
- Transport height
- 2.45 m
- Travel speed
- 20 km/h
- Max. discharge height
- 2.53 m
- Turning radius outside
- 2.84 m
- Lifting force
- 42.9 kN
- Engine manuf.
- Kohler
- Engine type
- KDI2504TCR
- Engine power
- 55.4 kW
- Displacement
- 2.482 l
- Max. torque
- 300/1500 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 88x102 mm
- Emission level
- V
More technical details, like: model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
Yes
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
