5075 Kramer 5075 Specifications & Technical Data (2015—2019)

The Kramer 5075 is a wheel loader manufactured by Kramer from 2015 to 2019. It has a weight of 4 tons and a transport length of 5.…

The Kramer 5075 is a wheel loader manufactured by Kramer from 2015 to 2019. It has a weight of 4 tons and a transport length of 5.08 meters. The bucket capacity ranges from 0.7 to 0.9 cubic meters, with a bucket width of 1.85 meters. The maximum discharge height is 2.4 meters, and it has a travel speed of 20 km/h. The transport width is 1.75 meters, and the transport height is 2.45 meters. The special equipment included is a quick hitch hydr.

5075

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 5075 Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4 t

Standard tyres: 12.5-18

Bucket width: 1.85 m

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 0.9 m³

Steering mode: AL

Transport length: 5.08 m

Transport width: 1.75 m

Transport height: 2.45 m

Travel speed: 20 km/h

Max. discharge height: 2.4 m

Engine manuf.: Yanmar

Engine type: 4TNV88

Engine power: 35 kW

Emission level: Tier 3 a

More technical details, like: turning radius outside, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer 5075 FAQ

When was the Kramer 5075 manufactured?

The Kramer 5075 was manufactured from 2015 to 2019.

How much does the Kramer 5075 wheel loader weigh?

The Kramer 5075 wheel loader weighs 4 tons.

What are the transport dimensions of the Kramer 5075 wheel loader?

The Kramer 5075 has a transport length of 5.08 meters, a transport width of 1.75 meters, and a transport height of 2.45 meters.

What is the travel speed of the Kramer 5075 wheel loader?

The Kramer 5075 has a travel speed of 20 km/h.

What is the standard tyre size of the Kramer 5075 wheel loader?

The standard tyre size of the Kramer 5075 wheel loader is 12.5-18.

What is the steering mode of the Kramer 5075?

The Kramer 5075 has all-wheel steering.

What is the maximum discharge height of the Kramer 5075?

The Kramer 5075 has a maximum discharge height of 2.4 meters.

What are the specifications of the bucket on the Kramer 5075 wheel loader?

The Kramer 5075 wheel loader has a bucket width of 1.85 meters, with a capacity ranging from 0.7 to 0.9 cubic meters.
