Technical specs - 5065T Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.35 t
- Standard tyres
- 12.0-18
- Bucket width
- 1.65 m
- Bucket capacity
- 0.65 m³
- Bucket capacity min.
- 0.65 m³
- Bucket capacity max.
- 1.1 m³
- Steering mode
- AL
- Transport length
- 5.35 m
- Transport width
- 1.59 m
- Transport height
- 2.47 m
- Travel speed
- 20 km/h
- Max. discharge height
- 3.5 m
- Turning radius outside
- 2.9 m
- Lifting force
- 32.5 kN
- Engine manuf.
- Yanmar
- Engine type
- 4TNV88C
- Engine power
- 34.3 kW
- Displacement
- 2.19 l
- Max. torque
- 135.8/1820 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 88x90 mm
- Emission level
- V
More technical details, like: model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
Yes
- Swing loader
-
No
- telescopic
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
