5035 Kramer 5035 Specifications & Technical Data (2014—2021)

The Kramer 5035 is a wheel loader manufactured by Kramer from 2014 to 2021. It has a weight of 1.63 tons and a transport length of…

The Kramer 5035 is a wheel loader manufactured by Kramer from 2014 to 2021. It has a weight of 1.63 tons and a transport length of 4.08 meters. The bucket capacity is 0.35 cubic meters with a bucket width of 1.25 meters. The maximum discharge height is 2.26 meters and it has a travel speed of 20 km/h. The transport width is 1.2 meters and the transport height is 1.99 meters. The turning radius outside is 1.95 meters. The machine is equipped with a quick hitch hydr. for special operations. The bucket capacity ranges from 0.35 to 0.65 cubic meters.

Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035
Wheel Loaders Kramer 5035

Technical specs - 5035 Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.63 t
Standard tyres
28x9.00-15
Bucket width
1.25 m
Bucket capacity
0.35 m³
Bucket capacity min.
0.35 m³
Bucket capacity max.
0.65 m³
Steering mode
AL
Transport length
4.08 m
Transport width
1.2 m
Transport height
1.99 m
Travel speed
20 km/h
Max. discharge height
2.26 m
Turning radius outside
1.95 m
Engine manuf.
Yanmar
Engine type
3TNV88
Engine power
23 kW
Displacement
1.642 l
Revolutions at max torque
107/11560 rpm
Emission level
III A

More technical details, like: lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kramer 5035 FAQ

When was the Kramer 5035 manufactured?

The Kramer 5035 was manufactured from 2014 to 2021.

How much does the Kramer 5035 wheel loader weigh?

The Kramer 5035 wheel loader weighs 1.63 tons.

What are the transport dimensions of the Kramer 5035 wheel loader?

The Kramer 5035 has a transport length of 4.08 meters, a transport width of 1.2 meters, and a transport height of 1.99 meters.

What is the travel speed of the Kramer 5035 wheel loader?

The Kramer 5035 has a travel speed of 20 km/h.

What are the standard tyres of the Kramer 5035 wheel loader?

The Kramer 5035 wheel loader is equipped with standard tyres sized 28x9.00-15.

What is the outside turning radius and steering mode of the Kramer 5035?

The Kramer 5035 wheel loader has an outside turning radius of 1.95 meters and features all-wheel steering.

What is the material handling capacity of the Kramer 5035 in terms of discharge height?

The Kramer 5035 has a maximum discharge height of 2.26 meters.

What are the specifications of the bucket on the Kramer 5035 wheel loader?

The Kramer 5035 wheel loader has a bucket with a capacity ranging from 0.35 to 0.65 cubic meters and a width of 1.25 meters.

How much is a Kramer 5035 Wheel loader (2014u20132021) worth?

The residual value of the Kramer 5035 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
