92Z V-2 Kawasaki 92Z V-2 Specifications & Technical Data (2010—2026)

The Kawasaki 92Z V-2 is a wheel loader manufactured since 2010. It has a weight of 26 tons and a bucket width of 3 meters. The max…

The Kawasaki 92Z V-2 is a wheel loader manufactured since 2010. It has a weight of 26 tons and a bucket width of 3 meters. The maximum discharge height is 3 meters, and it can travel at a speed of 35 km/h. The transport width and height are both 3 meters, and the turning radius outside is 7 meters. The bucket capacity ranges from 4 to 5 cubic meters.

92Z V-2

Years of manufacture: 2010—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 92Z V-2 Kawasaki

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 26.39 t

Standard tyres: 26.5 x 25

Bucket width: 3.17 m

Bucket capacity min.: 4 m³

Bucket capacity max.: 5 m³

Transport width: 3.035 m

Transport height: 3.55 m

Travel speed: 35.1 km/h

Max. discharge height: 3.255 m

Turning radius outside: 7.195 m

Engine manuf.: Cummins

Engine type: QSM11

Engine power: 223.7 kW

Displacement: 10.83 l

Revolutions at max torque: 1400 rpm

Max. torque: 1121 Nm

No. of cylinders: 6

Cylinder bore x stroke: 125 x 147.1 mm

More technical details, like: bucket capacity, steering mode, transport length, lifting force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

92Z V-2 Kawasaki Specification for North America (EN)

Kawasaki 92Z V-2 FAQ

When was the Kawasaki 92Z V-2 manufactured?

The Kawasaki 92Z V-2 was first produced in 2010.

How much does the Kawasaki 92Z V-2 wheel loader weigh?

The Kawasaki 92Z V-2 wheel loader weighs 26.39 tons.

What are the transport dimensions of the Kawasaki 92Z V-2?

The Kawasaki 92Z V-2 has a transport width of 3.04 meters and a transport height of 3.55 meters.

What is the travel speed of the Kawasaki 92Z V-2 wheel loader?

The Kawasaki 92Z V-2 has a travel speed of 35.1 km/h.

What are the undercarriage specifications of the Kawasaki 92Z V-2 wheel loader?

The Kawasaki 92Z V-2 wheel loader is equipped with standard tyres sized 26.5 x 25.

What is the outside turning radius of the Kawasaki 92Z V-2 wheel loader?

The Kawasaki 92Z V-2 has an outside turning radius of 7.195 meters.

What is the maximum discharge height of the Kawasaki 92Z V-2?

The Kawasaki 92Z V-2 has a maximum discharge height of 3.26 meters.

What are the specifications of the bucket on the Kawasaki 92Z V-2 wheel loader?

The Kawasaki 92Z V-2 wheel loader has a bucket with a capacity ranging from 4 to 5 cubic meters and a width of 3.17 meters.
