90Z V-2 Kawasaki 90Z V-2 Specifications & Technical Data (2010—2012)

The Kawasaki 90Z V-2 is a wheel loader manufactured from 2010 to 2012. It has a weight of 23 tons and a bucket width of 3 meters. …

The Kawasaki 90Z V-2 is a wheel loader manufactured from 2010 to 2012. It has a weight of 23 tons and a bucket width of 3 meters. The maximum discharge height is 3 meters, and it can travel at a speed of 35 km/h. The transport width is 2 meters, and the transport height is 3 meters. It has a turning radius outside of 7 meters. The bucket capacity ranges from a minimum of 2 cubic meters to a maximum of 4 cubic meters.

Wheel Loaders Kawasaki 90Z V-2

Technical specs - 90Z V-2 Kawasaki

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.68 t
Standard tyres
26.5 x 25
Bucket width
3.1 m
Bucket capacity min.
2.8 m³
Bucket capacity max.
4.5 m³
Transport width
2.93 m
Transport height
3.535 m
Travel speed
35.1 km/h
Max. discharge height
3.715 m
Turning radius outside
7.085 m
Engine manuf.
Cummins
Engine type
QSM11
Engine power
216.3 kW
Displacement
10.83 l
Revolutions at max torque
1400 rpm
Max. torque
1045 Nm
No. of cylinders
6
Cylinder bore x stroke
125 x 147.1 mm

More technical details, like: bucket capacity, steering mode, transport length, lifting force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kawasaki 90Z V-2 FAQ

When was the Kawasaki 90Z V-2 manufactured?

The Kawasaki 90Z V-2 was manufactured from 2010 to 2012.

How much does the Kawasaki 90Z V-2 weigh?

The Kawasaki 90Z V-2 weighs 23.68 tons.

What are the transport dimensions of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 has a transport width of 2.93 meters and a transport height of 3.54 meters.

What is the travel speed of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 has a travel speed of 35.1 km/h.

What are the undercarriage specifications of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 wheel loader is equipped with standard tyres sized 26.5 x 25.

What is the outside turning radius of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 has an outside turning radius of 7.085 meters.

What is the maximum discharge height of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 wheel loader has a maximum discharge height of 3.72 meters.

What are the bucket specifications of the Kawasaki 90Z V-2 wheel loader?

The Kawasaki 90Z V-2 wheel loader has a bucket width of 3.1 meters, with a capacity ranging from 2.8 to 4.5 cubic meters.
