TM320 Agri JCB TM320 Agri Specifications & Technical Data (2020—2026)

The JCB TM320 is a wheel loader manufactured by JCB since 2020. It has a weight of 9.2 tons and a transport length of 6.322 meters…

The JCB TM320 is a wheel loader manufactured by JCB since 2020. It has a weight of 9.2 tons and a transport length of 6.322 meters. The bucket capacity is 1 cubic meter with a width of 1.95 meters. The maximum discharge height is 4.511 meters and it has a travel speed of 40 km/h. The transport width is 2.35 meters and the transport height is 2.703 meters. The turning radius outside is 4.633 meters. It is equipped with a diesel particulate filter and has a telescopic feature.

Wheel Loaders JCB TM320 Agri

Visit JCB live at

Technical specs - TM320 Agri JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.2 t
Standard tyres
XMCL 460/70 R24
Bucket width
1.95 m
Bucket capacity
1 m³
Steering mode
KL
Transport length
6.322 m
Transport width
2.35 m
Transport height
2.703 m
Travel speed
40 km/h
Max. discharge height
4.511 m
Turning radius outside
4.633 m
Model series
TM
Engine manuf.
JCB
Engine type
EcoMax
Engine power
97 kW
Displacement
4.8 l
Revolutions at max torque
1500 rpm
Max. torque
550 Nm
No. of cylinders
4
Cylinder bore x stroke
106x139 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., lifting force, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB TM320 Agri FAQ

When was the JCB TM320 manufactured?

The JCB TM320 was first produced in 2020.

How much does the JCB TM320 wheel loader weigh?

The JCB TM320 wheel loader weighs 9.2 tons.

What are the transport dimensions of the JCB TM320 wheel loader?

The JCB TM320 has a transport length of 6.32 meters, a transport width of 2.35 meters, and a transport height of 2.7 meters.

What is the travel speed of the JCB TM320 wheel loader?

The JCB TM320 has a travel speed of 40 km/h.

What are the undercarriage specifications of the JCB TM320 wheel loader?

The JCB TM320 wheel loader is equipped with standard tyres sized XMCL 460/70 R24.

What are the maneuverability specifications of the JCB TM320 wheel loader?

The JCB TM320 has an articulated-frame steering system and an outside turning radius of 4.633 meters.

What is the material handling capacity of the JCB TM320 in terms of discharge height?

The JCB TM320 has a maximum discharge height of 4.51 meters.

What are the bucket specifications of the JCB TM320 wheel loader?

The JCB TM320 wheel loader has a bucket capacity of 1 cubic meter and a bucket width of 1.95 meters.

How much is a JCB TM320 Wheel loader (2020u20132025) worth?

The residual value of the JCB TM320 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
