Technical specs - 417 HT JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.8 t
- Standard tyres
- 17.5 R25 XHA
- Bucket width
- 2.4 m
- Bucket capacity
- 1.6 m³
- Bucket capacity min.
- 1.4 m³
- Steering mode
- KL
- Transport length
- 6.49 m
- Transport width
- 2.33 m
- Transport height
- 3.08 m
- Travel speed
- 40 km/h
- Max. discharge height
- 2.88 m
- Turning radius outside
- 5.35 m
- Lifting force
- 65 kN
- Model series
- 400
- Engine manuf.
- JCB
- Engine type
- EcoMax
- Engine power
- 97 kW
- Displacement
- 4.8 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 550 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 106x139 mm
- Emission level
- V
More technical details, like: bucket capacity max., dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
Yes
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
Yes
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
