    Lectura specs Construction machinery Wheel Loaders Wheel Loaders JCB JCB 409 specifications

    Technical specs - 409 JCB

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 5.93 t
    Standard tyres 405/70 R20
    Bucket width 1.95 m
    Bucket capacity 1 m³
    Bucket capacity min. 1 m³
    Steering mode KL
    Transport length 5.46 m
    Transport width 1.9 m
    Transport height 2.64 m
    Travel speed 20 km/h
    Max. discharge height 2.62 m
    Turning radius outside 4.43 m
    Lifting force 53.8 kN
    Engine manuf. Kohler
    Engine type KDI2054TCR
    Engine power 55.4 kW
    Engine power 74 HP
    Displacement 2.482 l
    Revolutions at max torque 1500 rpm
    Max. torque 300 Nm
    No. of cylinders 4
    Emission level V
    Bucket capacity max. ###
    Dimension lxwxh ###
    Cylinder bore x stroke ###
    Weight ###

    Basic model with ROPS cabin, std. shovel and teeth

    409 JCB - Special equipment

    • Diesel particulate filter
    • Pivoting loader
    • telescopic
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.

    Download data sheets - JCB 409
